Name: 1243060000
Brand: Weidmüller
SKU: 1243060000
Price: 3.08000 USD
Availability: InStock

new-10%

1243060000

Manufacturer part number:1243060000

Manufacturer:Weidmüller

Description:1243060000 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Weidmüller stock available on our website

Case Package:SOT-23

Datasheet:1243060000 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	12 Weeks
Contact Material	Copper Alloy
Mounting Type	Through Hole
Housing Material	Polybutylene Terephthalate (PBT), Glass Filled
Operating Temperature	-50°C~120°C
Packaging	Bulk
Published	2008
Series	Unimate SLA
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Type	Header, Male Pins, Shrouded (4 Side)
Number of Positions	7
Color	Orange
Number of Rows	2
Gender	Male
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	0.200 5.08mm
Total Number of Contacts	7
Orientation	Straight
Depth	9.4mm
Insulation Height	0.472 12.00mm
Termination Style	Solder
UL Flammability Code	94V-0
Contact Tail Length	0.126 3.20mm
Max Current Rating	10A
Number of Levels	1
Contact Mating Finish	Tin
Voltage - UL	300V
Voltage - IEC	400V
Header Orientation	Vertical
Current - IEC	17.5A
Length	37.56mm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	RoHS Compliant

1243060000 Product Details

1243060000 Overview

This device has a Through Hole mounting type.We package the product with a Bulk case.Unimate SLA Series product.-50°C~120°C Operating Temperature is the default operating temperature for the device.As with other Header, Male Pins, Shrouded (4 Side) products, this part also offers a wide range of benefits.
