691241700007

  • 691241700007 - 0.197 5.00mm Green Bulk Polyamide (PA66), Nylon 6/6 Through Hole Vertical with Board Screw - Rising Cage Clamp 1 Levels 14-30 AWG WR-TBL Series 2417
  • 691241700007 - 0.197 5.00mm Green Bulk Polyamide (PA66), Nylon 6/6 Through Hole Vertical with Board Screw - Rising Cage Clamp 1 Levels 14-30 AWG WR-TBL Series 2417

691241700007

691241700007

Würth Elektronik

0.197 5.00mm Green Bulk Polyamide (PA66), Nylon 6/6 Through Hole Vertical with Board Screw - Rising Cage Clamp 1 Levels 14-30 AWG WR-TBL Series 2417

SOT-23

691241700007 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 10 Weeks
Mounting Type Through Hole
Housing Material Polyamide (PA66), Nylon 6/6
Contact Material - Plating Copper Alloy - Nickel Plated
Clamp Material - Plating Copper Alloy
Screw Material - Plating Steel - Zinc Plated
Operating Temperature-30°C~120°C
PackagingBulk
Series WR-TBL Series 2417
Part StatusActive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Color Green
Pitch 0.197 5.00mm
Wire Gauge14-30 AWG
Voltage 300V
Number of Levels 1
Current 14A
Torque - Screw 0.45 Nm (4.0 Lb-In)
Positions Per Level 7
Mating Orientation Vertical with Board
Wire TerminationScrew - Rising Cage Clamp
Screw Thread M3
RoHS StatusROHS3 Compliant
In-Stock:1577 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$3.96000$3.96
500$3.9204$1960.2
1000$3.8808$3880.8
1500$3.8412$5761.8
2000$3.8016$7603.2
2500$3.762$9405

691241700007 Product Details

691241700007 Overview


Mounting type Through Hole is selected for the device.Packaged in a Bulk case.A member of the WR-TBL Series 2417 Series.Device runs in -30°C~120°C operating temperature.

691241700007 Features


WR-TBL Series 2417 series


691241700007 Applications


There are a lot of Würth Elektronik
691241700007 Terminal Blocks applications.


  • Military Technology
  • Measuring & Control Technology
  • Instrumentation
  • Automotive Electronics
  • Telecommunications
  • Data Technology
  • Blowers
  • Control panels
  • Electrical substations
  • Energy efficient lighting (LED)
