Name: SI2305DS-T1-E3
Brand: Vishay Siliconix
SKU: SI2305DS-T1-E3
Availability: InStock

new-10%

SI2305DS-T1-E3

Manufacturer part number:SI2305DS-T1-E3

Manufacturer:Vishay Siliconix

Description:Trans MOSFET P-CH 8V 3.5A 3-Pin SOT-23 T/R

Case Package:SOT-23

Datasheet:SI2305DS-T1-E3 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	TO-236-3, SC-59, SOT-23-3
Number of Pins	3
Packaging	Cut Tape (CT)
Published	2008
Series	TrenchFET®
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	3
Termination	SMD/SMT
ECCN Code	EAR99
Resistance	52mOhm
Terminal Finish	Matte Tin (Sn)
Max Operating Temperature	150°C
Min Operating Temperature	-55°C
Max Power Dissipation	1.25W
Technology	MOSFET (Metal Oxide)
Terminal Position	DUAL
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
[email protected] Reflow Temperature-Max (s)	30
Pin Count	3
Number of Elements	1
Element Configuration	Single
Operating Mode	ENHANCEMENT MODE
Power Dissipation	1.25W
Turn On Delay Time	13 ns
FET Type	P-Channel
Rds On (Max) @ Id, Vgs	52m Ω @ 3.5A, 4.5V
Vgs(th) (Max) @ Id	800mV @ 250μA
Input Capacitance (Ciss) (Max) @ Vds	1245pF @ 4V
Current - Continuous Drain (Id) @ 25°C	3.5A Ta
Gate Charge (Qg) (Max) @ Vgs	15nC @ 4.5V
Rise Time	25ns
Fall Time (Typ)	25 ns
Turn-Off Delay Time	55 ns
Continuous Drain Current (ID)	3.5A
Threshold Voltage	-800mV
Gate to Source Voltage (Vgs)	8V
Drain to Source Breakdown Voltage	8V
Dual Supply Voltage	-8V
Nominal Vgs	-800 mV
Width	1.397mm
Radiation Hardening	No
REACH SVHC	Unknown
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free
