V30DM45CHM3/I

  • V30DM45CHM3/I - V30DM45CHM3/I datasheet pdf and Diodes - Rectifiers - Arrays product details from Vishay Semiconductor Diodes Division stock available on our website
  • V30DM45CHM3/I - V30DM45CHM3/I datasheet pdf and Diodes - Rectifiers - Arrays product details from Vishay Semiconductor Diodes Division stock available on our website

V30DM45CHM3/I

V30DM45CHM3/I

Vishay Semiconductor Diodes Division

V30DM45CHM3/I datasheet pdf and Diodes - Rectifiers - Arrays product details from Vishay Semiconductor Diodes Division stock available on our website

SOT-23

V30DM45CHM3/I Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 10 Weeks
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab) Variant
Supplier Device Package TO-263AC (SMPD)
PackagingTape & Reel (TR)
Published 2018
Series Automotive, AEC-Q101, eSMP®, TMBS®
Part StatusActive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 700μA @ 45V
Voltage - Forward (Vf) (Max) @ If 600mV @ 15A
Operating Temperature - Junction -40°C~175°C
Voltage - DC Reverse (Vr) (Max) 45V
Current - Average Rectified (Io) 15A
Diode Configuration 1 Pair Common Cathode
RoHS StatusROHS3 Compliant
In-Stock:3897 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$1.589165$1.589165
10$1.499213$14.99213
100$1.414351$141.4351
500$1.334293$667.1465
1000$1.258768$1258.768

V30DM45CHM3/I Product Details

V30DM45CHM3/I Overview




V30DM45CHM3/I Features



V30DM45CHM3/I Applications


There are a lot of Vishay Semiconductor Diodes Division V30DM45CHM3/I applications of rectifier diode array.

  • Crowbar applications
  • Free wheeling diode in low voltage converters
  • Rectifier for drives applications
  • Rectifiers in switch mode power supplies (SMPS)
  • Battery chargers
  • Rectifiers for UBS
  • General Rectification
