Name: VS-303CNQ100PBF
Brand: Vishay Semiconductor Diodes Division
SKU: VS-303CNQ100PBF
Price: 56.85000 USD
Availability: InStock

new

VS-303CNQ100PBF

Manufacturer part number:VS-303CNQ100PBF

Manufacturer:Vishay Semiconductor Diodes Division

Description:VS-303CNQ100PBF datasheet pdf and Diodes - Rectifiers - Arrays product details from Vishay Semiconductor Diodes Division stock available on our website

Case Package:SOT-23

Datasheet:VS-303CNQ100PBF Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	22 Weeks
Mount	Chassis Mount, Panel, Screw
Mounting Type	Chassis Mount
Package / Case	TO-244AB
Number of Pins	3
Diode Element Material	SILICON
Packaging	Bulk
Published	2008
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
ECCN Code	EAR99
Max Operating Temperature	175°C
Min Operating Temperature	-55°C
Additional Feature	FREE WHEELING DIODE, UL APPROVED
Terminal Position	UPPER
Terminal Form	UNSPECIFIED
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Reach Compliance Code	unknown
[email protected] Reflow Temperature-Max (s)	NOT SPECIFIED
JESD-30 Code	R-PUFM-X2
Number of Elements	2
Element Configuration	Common Cathode
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Diode Type	Schottky
Current - Reverse Leakage @ Vr	4.5mA @ 100V
Voltage - Forward (Vf) (Max) @ If	1.09V @ 300A
Forward Current	300A
Max Reverse Leakage Current	4.5mA
Operating Temperature - Junction	175°C Max
Max Surge Current	22kA
Application	GENERAL PURPOSE
Forward Voltage	1.09V
Max Reverse Voltage (DC)	100V
Average Rectified Current	150A
Number of Phases	1
Peak Reverse Current	4.5mA
Max Repetitive Reverse Voltage (Vrrm)	100V
Peak Non-Repetitive Surge Current	22kA
Diode Configuration	1 Pair Common Cathode
Max Forward Surge Current (Ifsm)	22kA
Height	17.5mm
Length	93mm
Width	21mm
RoHS Status	ROHS3 Compliant

VS-303CNQ100PBF Product Details

VS-303CNQ100PBF Overview

In operation, this device will be set to 1.09V volts forward.Array is important to monArrayor the surge current and make sure that Array does not exceed 22kA.A forward voltage of 300A will enable the device to operate.In devices such as this one, reverse voltage peak is set at 4.5mA.When reverse biased, its maximum reverse leakage current is 4.5mA, which is the current coming from that semiconductor device.
