MKP386M520160YT8

  • MKP386M520160YT8 - MKP386M 2μF Film Capacitor ±5% Rectangular Box Screw Terminals 1.6kV-DC 600V-AC Polypropylene (PP), Metallized Chassis Mount
  • MKP386M520160YT8 - MKP386M 2μF Film Capacitor ±5% Rectangular Box Screw Terminals 1.6kV-DC 600V-AC Polypropylene (PP), Metallized Chassis Mount

MKP386M520160YT8

MKP386M520160YT8

Vishay BC Components

MKP386M 2μF Film Capacitor ±5% Rectangular Box Screw Terminals 1.6kV-DC 600V-AC Polypropylene (PP), Metallized Chassis Mount

SOT-23

MKP386M520160YT8 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 16 Weeks
Mount Chassis Mount
Mounting Type Chassis Mount
Package / Case Rectangular Box
Dielectric MaterialPolypropylene (PP), Metallized
Operating Temperature-55°C~105°C
PackagingBulk
Published 2007
Series MKP386M
Size / Dimension 2.283Lx1.181W 58.00mmx30.00mm
Tolerance ±5%
JESD-609 Code e3
Feature Low ESR
Pbfree Code yes
Part StatusActive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination Screw Terminals
ECCN Code EAR99
Terminal Finish Tin (Sn)
Applications Snubber
Capacitance 2μF
Voltage - Rated DC 1.6kV
Voltage - Rated AC 600V
Lead Pitch 26.0096mm
Capacitor Type FILM CAPACITOR
ESR (Equivalent Series Resistance) 2.5mOhm
Lead Spacing1.024 26.00mm
Height Seated (Max) 1.772 45.00mm
RoHS StatusROHS3 Compliant
In-Stock:776 items

Pricing & Ordering

QuantityUnit PriceExt. Price
225$10.80000$2430

MKP386M520160YT8 Product Details

MKP386M520160YT8 Overview


A device with a 2.5mOhm ESR (Equivalent Series Resistance) has been identified.Electrical devices have 1.024 26.00mm lead spacing.Temperatures of -55°C~105°C are suitable for operating the device.

MKP386M520160YT8 Features


2.5mOhm equivalent series resistance (ESR)


MKP386M520160YT8 Applications


There are a lot of Vishay BC Components
MKP386M520160YT8 applications of film capacitors.


  • RF Modules
  • Mobile communications
  • Satellite TV
  • Global positioning systems
  • Filters
  • VCO's
  • Matching networks
  • Snubbering
  • Filtering
  • IGBT
