Name: TPS78601DCQRG4
Brand: Texas Instruments
SKU: TPS78601DCQRG4
Availability: InStock

new-10%

TPS78601DCQRG4

Manufacturer part number:TPS78601DCQRG4

Manufacturer:Texas Instruments

Description:Enable Adjustable TPS78601 PMIC 6 SOT-223-6

Case Package:SOT-23

Datasheet:TPS78601DCQRG4 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Lifecycle Status	ACTIVE (Last Updated: 3 days ago)
Factory Lead Time	6 Weeks
Mounting Type	Surface Mount
Package / Case	SOT-223-6
Surface Mount	YES
Number of Pins	6
Operating Temperature	-40°C~125°C
Packaging	Tape & Reel (TR)
JESD-609 Code	e4
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	2 (1 Year)
ECCN Code	EAR99
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Position	DUAL
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
Base Part Number	TPS78601
Pin Count	6
Number of Outputs	1
Output Voltage	5.5V
Output Type	Adjustable
Max Output Current	1.5A
Output Configuration	Positive
Quiescent Current	200μA
Control Features	Enable
Accuracy	3 %
Max Output Voltage	5.5V
Voltage - Output (Min/Fixed)	1.2V
Number of Regulators	1
Min Input Voltage	2.7V
Protection Features	Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Current - Quiescent (Iq)	385μA
Voltage Dropout (Max)	0.47V @ 1.5A
PSRR	59dB ~ 32dB (100Hz ~ 100kHz)
Reference Voltage	1.225V
Dropout Voltage	305mV
Min Output Voltage	1.22V
Min Current Limit	2.4A
Input Bias Current	310μA
Output Voltage Accuracy	3 %
Height	1.8mm
Length	6.5mm
Width	3.5mm
Thickness	1.6mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

TPS78601DCQRG4 Product Details

TPS78601DCQRG4 Overview

This Voltage Regulator IC comes inTape & Reel (TR) packaging. This battery regulator is contained in a SOT-223-6 package. The IC chip's output type is Adjustable. This electronic component implements 1 regulators. The Linear Voltage Regulator's mounting type is Surface Mount. The IC Regulator is set to operate at -40°C~125°C degrees. This regulator's output function is configured to be Positive. IC voltage regulator has a sum of 6 pins. To ensure prompt, sufficient performance, this part features 1 outputs in total. Its dropout voltage is 10 volts. The component's pin number remains 6. FYI, the basic part number for this IC regulator is TPS78601. It works in 1.5A output current at mostIt operates in the 200μA Quiescent Current state.
