Name: TMS5703137CGWTQEP
Brand: Texas Instruments
SKU: TMS5703137CGWTQEP
Availability: InStock

new-10%

TMS5703137CGWTQEP

Manufacturer part number:TMS5703137CGWTQEP

Manufacturer:Texas Instruments

Description:3MB 3M x 8 FLASH ARM® Cortex®-R4F 16/32-Bit Microcontroller Hercules™ TMS570 ARM® Cortex®-R Series 5703137 337 Pin 180MHz 1.2V 337-LFBGA

Case Package:SOT-23

Datasheet:TMS5703137CGWTQEP Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Lifecycle Status	ACTIVE (Last Updated: 6 days ago)
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	337-LFBGA
Number of Pins	337
Operating Temperature	-40°C~125°C TA
Packaging	Tube
Series	Hercules™ TMS570 ARM® Cortex®-R
JESD-609 Code	e0
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	337
Terminal Finish	Tin/Lead (Sn/Pb)
Additional Feature	ALSO REQUIRES 3.3 V I/O SUPPLY
Terminal Position	BOTTOM
Terminal Form	BALL
Peak Reflow Temperature (Cel)	220
Supply Voltage	1.2V
Terminal Pitch	0.8mm
Frequency	180MHz
Base Part Number	5703137
Pin Count	337
Operating Supply Voltage	1.2V
Interface	CAN, EBI/EMI, Ethernet, I2C, LIN, SCI, SPI, UART, USART
Memory Size	3MB
Oscillator Type	External
Number of I/O	120
RAM Size	256K x 8
Voltage - Supply (Vcc/Vdd)	1.14V~1.32V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	ARM® Cortex®-R4F
Peripherals	DMA, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	16/32-Bit
Program Memory Size	3MB 3M x 8
Connectivity	CANbus, EBI/EMI, Ethernet, FlexRay, I2C, LINbus, MibSPI, SCI, SPI, UART/USART
Supply Current-Max	440mA
Bit Size	32
Data Converter	A/D 16x12b, 24x12b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	YES
Data Bus Width	32b
PWM Channels	YES
Number of Timers/Counters	2
Core Architecture	ARM
CPU Family	CORTEX-R4F
Boundary Scan	YES
Low Power Mode	YES
Format	FLOATING-POINT
Integrated Cache	NO
RAM (words)	256
Number of ADC Channels	24
Number of Serial I/Os	11
Number of GPIO	144
Height	1.4mm
Length	16mm
Width	16mm
Thickness	900μm
Radiation Hardening	No
RoHS Status	Non-RoHS Compliant
Lead Free	Contains Lead

TMS5703137CGWTQEP Product Details

TMS5703137CGWTQEP Description

TMS5703137CGWTQEP microcontroller features the highest performance and offer a broad selection of upgraded connectivity and inputs. TMS5703137CGWTQEP datasheet is an excellent option for a variety of smaller and medium-sized tasks and full platform solutions. TMS5703137CGWTQEP MCU is suitable for Motor drive, Medical equipment, Industrial applications, Printers, and scanners, Alarm systems, and Home audio appliances.

TMS5703137CGWTQEP Features

Clock management

HDMI CEC wakeup on header reception

CRC calculation unit

Reset and power management

TMS5703137CGWTQEP Applications

Motor drive

Medical equipment

Industrial applications

Printers, and scanners
