Name: MSP430FR2673TRHBR
Brand: Texas Instruments
SKU: MSP430FR2673TRHBR
Price: 4.62000 USD
Availability: InStock

new-10%

MSP430FR2673TRHBR

Manufacturer part number:MSP430FR2673TRHBR

Manufacturer:Texas Instruments

Description:Microcontroller 3V

Case Package:SOT-23

Datasheet:MSP430FR2673TRHBR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	42 Weeks
Surface Mount	YES
JESD-609 Code	e4
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	2 (1 Year)
Number of Terminations	32
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Technology	CMOS
Terminal Position	QUAD
Terminal Form	NO LEAD
Supply Voltage	3V
Terminal Pitch	0.5mm
Reach Compliance Code	compliant
JESD-30 Code	S-PQCC-N32
Operating Temperature (Max)	105°C
Operating Temperature (Min)	-40°C
Supply Voltage-Max (Vsup)	3.6V
Temperature Grade	INDUSTRIAL
Supply Voltage-Min (Vsup)	1.8V
Number of I/O	27
Speed	16 MHz
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Clock Frequency	0.032MHz
Supply Current-Max	3.75mA
Bit Size	16
Has ADC	YES
DMA Channels	NO
PWM Channels	YES
DAC Channels	NO
ROM (words)	16384
On Chip Program ROM Width	8
CPU Family	MSP430
Boundary Scan	YES
Low Power Mode	YES
Format	FLOATING-POINT
Integrated Cache	NO
RAM (words)	2048
RAM (bytes)	4096
Number of Serial I/Os	2
Number of Timers	5
ROM Programmability	FRAM
On Chip Data RAM Width	16
Height Seated (Max)	1mm
Length	5mm
Width	5mm
RoHS Status	RoHS Compliant

MSP430FR2673TRHBR Product Details

MSP430FR2673TRHBR Overview

27 I/Os are available. This device falls under the MICROCONTROLLER, RISC uPs/uCs/Peripheral ICs category. 32 is the number of terminations on the IC chip that are present. This part works in a 16-bit manner. There is a 3V volt supply output on the chip. DMA channels number NO. The device works in YES PWM channels. In this device, there is a MSP430 CPU embedded within it. A 0.032MHz-clock frequency is used to operate it. There are 2 serial I/Os incorporated into the chip part. It is possible to have 5 bits in a IC chip.
