Name: PIC16F1508-I/SO
Brand: Microchip Technology
SKU: PIC16F1508-I/SO
Price: 1.73000 USD
Availability: InStock

new-10%

PIC16F1508-I/SO

Manufacturer part number:PIC16F1508-I/SO

Manufacturer:Microchip Technology

Description:7KB 4K x 14 FLASH PIC 8-Bit Microcontroller PIC® XLP™ 16F Series PIC16F1508 20 Pin 20MHz 5V 20-SOIC (0.295, 7.50mm Width)

Case Package:SOT-23

Datasheet:PIC16F1508-I/SO Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	7 Weeks
Mounting Type	Surface Mount
Package / Case	20-SOIC (0.295, 7.50mm Width)
Surface Mount	YES
Number of Pins	20
Supplier Device Package	20-SOIC
Mounting Style	SMD/SMT
Interfaces	I2C/SPI/USART
Data Converters	A/D 12x10b, D/A 1x5b
MSL	MSL 1 - Unlimited
Qualification	AEC-Q100
Number of I/Os	18 I/O
Maximum Operating Temperature	+ 85 C
Minimum Operating Temperature	- 40 C
Manufacturer	Microchip
Brand	Microchip Technology / Atmel
Tradename	PIC
RoHS	Details
Package	Tube
Base Product Number	PIC16F1508
Mfr	Microchip Technology
Product Status	Active
Operating Temperature	-40°C~85°C TA
Packaging	Tube
Series	PIC® XLP™ 16F
Published	1999
JESD-609 Code	e3
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	20
ECCN Code	EAR99
Terminal Finish	Matte Tin (Sn)
Max Power Dissipation	800mW
Terminal Position	DUAL
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
Supply Voltage	5V
Frequency	20MHz
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	PIC16F1508
Pin Count	20
Supply Voltage-Max (Vsup)	5.5V
Power Supplies	2.5/5V
Supply Voltage-Min (Vsup)	2.5V
Interface	I2C, LIN, SPI, UART, USART
Memory Size	7kB
Oscillator Type	Internal
Number of I/O	17
Nominal Supply Current	850μA
Speed	20MHz
RAM Size	256 x 8
Voltage - Supply (Vcc/Vdd)	2.3V~5.5V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	PIC
Peripherals	Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	8-Bit
Program Memory Size	7KB 4K x 14
Connectivity	I2C, LINbus, SPI, UART/USART
Bit Size	8
Data Converter	A/D 12x10b; D/A 1x5b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	NO
Data Bus Width	8b
Number of Timers/Counters	3
Address Bus Width	8b
Product Type	8-bit Microcontrollers - MCU
EEPROM Size	--
CPU Family	PIC
Number of Programmable I/O	18
Number of ADC Channels	12
Number of PWM Channels	4
Number of I2C Channels	1
Product	MCU
Product Category	8-bit Microcontrollers - MCU
Device Core	PIC
Height	2.05mm
Length	12.8mm
Width	7.5mm
REACH SVHC	No SVHC
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

PIC16F1508-I/SO Product Details

PIC16F1508-I/SO Description

A low-cost, high-performance 8-bit microcontroller with integrated Flash memory is the Microchip Technologies PIC16F1508-I/SO. It is based on the PIC16 architecture and is a member of the PIC16F microcontroller family. Applications for the PIC16F1508-I/SO include industrial control, consumer electronics, automotive, and medical equipment. A wide range of peripherals, such as numerous timers, comparators, and communication interfaces, are included. Moreover, the gadget has on-board Flash memory for storing programs, enabling simple firmware changes. The PIC16F1508-I/SO is a well-liked option for developers wishing to construct reliable and affordable control solutions thanks to its low power consumption, extensive functionality, and adaptable development tools.
