Name: 6-104656-0
Brand: TE Connectivity AMP Connectors
SKU: 6-104656-0
Price: 10.75000 USD
Availability: InStock

new

6-104656-0

Manufacturer part number:6-104656-0

Manufacturer:TE Connectivity AMP Connectors

Description:CONN HEADER 100POS .050 VERT SMD

Case Package:SOT-23

Datasheet:6-104656-0 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	22 Weeks
Lifecycle Status	ACTIVE (Last Updated: 5 months ago)
Contact Material	Phosphor Bronze
Contact Plating	Gold, Tin
Mount	Surface Mount
Mounting Type	Surface Mount
Contact Shape	Circular
Insulation Material	Liquid Crystal Polymer (LCP)
Housing Material	Thermoplastic
Underplate Material	Nickel
Operating Temperature	-65°C~105°C
Packaging	Tube
Published	2006
Series	AMPMODU 50/50 Grid
Feature	Board Lock
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
ECCN Code	EAR99
Connector Type	Header
Number of Positions	100
Applications	Automotive, General Purpose, Medical, Military, Telecommunications
Number of Rows	2
Gender	Male
Voltage - Rated	30V
HTS Code	8536.69.40.40
Fastening Type	Push-Pull
Contact Finish - Mating	Gold
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Contact Type	Male Pin
Mixed Contacts	NO
Current Rating (Amps)	0.5A per Contact
Total Number of Contacts	100
Orientation	Vertical
Depth	5.71mm
Insulation Height	0.298 7.57mm
Style	Board to Board
Number of Positions Loaded	All
Current Rating	4A
Pitch - Mating	0.050 1.27mm
Insulation Color	Black
Number of Conductors	ONE
Reference Standard	UL
Voltage - Rated AC	30V
Reliability	COMMERCIAL
Approval Agency	CSA
Row Spacing - Mating	0.050 (1.27mm)
Shrouding	Shrouded - 4 Wall
Number Of PCB Rows	2
Contact Finish - Post	Tin
Contact Length - Mating	0.120 3.05mm
PCB Contact Pattern	RECTANGULAR
UL Flammability Code	94V-0
Operating Supply Voltage	30V
Contact Resistance	16mOhm
Insulation Resistance	5000000000Ohm
Mating Contact Pitch	0.05 inch
ELV	Compliant
Max Voltage Rating (AC)	30V
Polarization Key	POLARIZED HOUSING
Dielectric Withstanding Voltage	300VAC V
Contact Current Rating	4A
Mating Post Length	3.048mm
Keyed	Yes
Shrouded End Dimension	914.4 μm
Length	66.59mm
Plating Thickness	30μin
Contact Finish Thickness - Mating	30.0μin 0.76μm
Contact Finish Thickness - Post	150.0μin 3.81μm
Stack Height (Mating)	8.13mm
Stack Height	8.128mm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

About 6-104656-0

The 6-104656-0 from TE Connectivity AMP Connectors is a high-performance microcontroller designed for a wide range of embedded applications. This component features CONN HEADER 100POS .050 VERT SMD.

Key Features

Advanced AVR architecture for efficient processing
Wide operating temperature range: -40°C to 85°C
Low power consumption for energy-efficient applications
Comprehensive peripheral set including SPI, UART, and USART interfaces

Applications

This microcontroller is ideal for various applications including:

Industrial control systems
Consumer electronics
Automotive systems
IoT devices
Medical equipment

Technical Support

Hotenda provides comprehensive technical support for the 6-104656-0, including datasheets, application notes, and design resources. Our team of engineers is available to assist with your design challenges.
