Name: DF1B-15P-2.5DS(01)
Brand: Hirose Electric Co Ltd
SKU: DF1B-15P-2.5DS(01)
Price: 1.90000 USD
Availability: InStock

new-10%

DF1B-15P-2.5DS(01)

Manufacturer part number:DF1B-15P-2.5DS(01)

Manufacturer:Hirose Electric Co Ltd

Description:DF1B-15P-2.5DS(01) datasheet pdf and Rectangular Connectors - Headers, Male Pins product details from Hirose Electric Co Ltd stock available on our website

Case Package:SOT-23

Datasheet:DF1B-15P-2.5DS(01) Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	10 Weeks
Contact Material	Brass
Mount	Through Hole
Mounting Type	Through Hole, Right Angle
Contact Shape	Square
Insulation Material	Polyamide (PA), Nylon
Housing Material	Polyamide
Operating Temperature	-35°C~85°C
Packaging	Bulk
Series	DF1B
JESD-609 Code	e3/e4
Feature	Keying Slot
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
ECCN Code	EAR99
Connector Type	Header
Number of Positions	15
Number of Rows	1
Gender	Male
HTS Code	8536.69.40.40
Fastening Type	Push-Pull
Contact Finish - Mating	Gold
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Contact Type	Male Pin
Mixed Contacts	NO
Option	GENERAL PURPOSE
Insulation Height	0.224 5.69mm
Style	Board to Cable/Wire
Number of Positions Loaded	All
Reach Compliance Code	unknown
Current Rating	3A
Pitch - Mating	0.098 2.50mm
Number of Conductors	ONE
Reference Standard	UL, CSA
Voltage - Rated AC	250V
Reliability	COMMERCIAL
Contact Length - Post	0.142 3.60mm
Shrouding	Shrouded - 4 Wall
Number Of PCB Rows	1
Lead Pitch	2.5mm
Contact Length - Mating	0.177 4.50mm
PCB Contact Pattern	RECTANGULAR
Mating Information	MULTIPLE MATING PARTS AVAILABLE
Body Breadth	0.224 inch
UL Flammability Code	94V-0
Housing Color	White
Body Depth	0.492 inch
Rated Current (Signal)	3A
Contact Resistance	30mOhm
Mating Contact Pitch	0.098 inch
Polarization Key	POLARIZED HOUSING
Dielectric Withstanding Voltage	650VAC V
Durability	50 Cycles
Insertion Force-Max	4.3924 N
Height	5.7mm
Length	40mm
Contact Finish Thickness - Mating	8.00μin 0.203μm
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS Compliant
Lead Free	Lead Free

DF1B-15P-2.5DS(01) Product Details

DF1B-15P-2.5DS(01) Overview

Packaging is Header.Through Hole, Right Angle is the mounting type.It's packaged in a Bulk case.The product is a part of the DF1B Series.Many aspects of its Keying Slot feature increase its effectiveness.Part Through Hole is mounted to the part.The device runs in -35°C~85°C Operating Temperature.
