Name: 1-282901-2
Brand: TE Connectivity AMP Connectors
SKU: 1-282901-2
Price: 12.78000 USD
Availability: InStock

new

1-282901-2

Manufacturer part number:1-282901-2

Manufacturer:TE Connectivity AMP Connectors

Description:0.200 5.08mm Green Bulk Polyamide (PA66), Nylon 6/6 Through Hole Horizontal with Board Screw - Rising Cage Clamp 1 Levels 12-30 AWG Buchanan

Case Package:SOT-23

Datasheet:1-282901-2 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Lifecycle Status	ACTIVE (Last Updated: 4 days ago)
Factory Lead Time	13 Weeks
Contact Material	Brass
Contact Plating	Tin
Mount	Through Hole
Mounting Type	Through Hole
Housing Material	Polyamide (PA66), Nylon 6/6
Contact Material - Plating	Brass - Tin Plated
Clamp Material - Plating	Brass - Nickel Plated
Screw Material - Plating	Brass - Nickel Plated
Operating Temperature	-40°C~105°C
Packaging	Bulk
Series	Buchanan
Published	2010
Feature	Interlocking (Side), Mid Wire Entry Level, Positions Stamped
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Screw
ECCN Code	EAR99
Connector Type	Receptacle
Number of Positions	12
Color	Green
Voltage - Rated	300V
HTS Code	8536.69.40.40
Pitch	0.200 5.08mm
Orientation	Straight
Depth	10.2mm
Wire Gauge	12-30 AWG
ELV	Compliant
Max Current Rating	17.5A
Number of Levels	1
Wire Gauge (Max)	30 AWG
Wire Gauge (Min)	12 AWG
Terminal and Terminal Block Type	BARRIER STRIP TERMINAL BLOCK
Torque - Screw	0.79 Nm (7.0 Lb-In)
Positions Per Level	12
Mating Orientation	Horizontal with Board
Wire Termination	Screw - Rising Cage Clamp
Screw Thread	M3
Length	60.96mm
Length - Tail	3.81mm
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0

1-282901-2 Product Details

1-282901-2 Overview

Packaging for this item is Receptacle.There is a mounting type of Through Hole for this device.It is necessary to use a Bulk case for packaging the product.This product is part of the Buchanan Series.In many ways, its Interlocking (Side), Mid Wire Entry Level, Positions Stamped feature makes it more powerful.Through Hole is used to mount the part.In this case, the device operates at -40°C~105°C Operating Temperature.

1-282901-2 Features

Buchanan series

1-282901-2 Applications

There are a lot of TE Connectivity AMP Connectors
1-282901-2 Terminal Blocks applications.

Transportation
Embedded systems
Datacom
Communication
Medical technology
Military Technology
Measuring & Control Technology
Instrumentation
Automotive Electronics
Telecommunications

Quantity	Unit Price	Ext. Price
1	$10.26000	$10.26
10	$9.02800	$90.28
25	$8.51560	$212.89
50	$8.10500	$405.25
100	$7.95120	$795.12
250	$6.92524	$1731.31
500	$6.66876	$3334.38

1-282901-2

1-282901-2

Technical Specifications

In-Stock:710 items
