Name: 1-102387-3
Brand: TE Connectivity AMP Connectors
SKU: 1-102387-3
Price: 6.73000 USD
Availability: InStock

new

1-102387-3

Manufacturer part number:1-102387-3

Manufacturer:TE Connectivity AMP Connectors

Description:1-102387-3 datasheet pdf and Rectangular Connectors - Housings product details from TE Connectivity AMP Connectors stock available on our website

Case Package:SOT-23

Datasheet:1-102387-3 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	10 Weeks
Lifecycle Status	ACTIVE (Last Updated: 2 days ago)
Contact Material	Copper
Mount	Cable, Free Hanging
Mounting Type	Free Hanging (In-Line)
Housing Material	Thermoplastic
Packaging	Bulk
Published	2008
Series	AMPMODU Mod IV
Feature	Polarizing Key
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN Code	EAR99
Connector Type	Receptacle
Number of Positions	44
Max Operating Temperature	105°C
Min Operating Temperature	-65°C
Color	Black
Number of Rows	2
Additional Feature	POLARIZED, SHROUDED
HTS Code	8536.69.40.40
Subcategory	Headers and Edge Type Connectors
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Contact Type	Female Socket
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	0.100 2.54mm
Total Number of Contacts	44
Orientation	Straight
Depth	15.24mm
Current Rating	3A
Voltage - Rated AC	250V
Reliability	COMMERCIAL
Approval Agency	CSA
Mating Information	MULTIPLE MATING PARTS AVAILABLE
Contact Gender	Female
Operating Supply Voltage	250V
Rated Current (Signal)	3A
Insulation Resistance	5GOhm
Row Spacing	0.100 (2.54mm)
Note	Contacts Not Included
Body/Shell Style	PLUG
ELV	Compliant
Max Voltage Rating (AC)	250V
Polarization Key	CENTER
Wire Gauge (Max)	30 AWG
Wire Gauge (Min)	22 AWG
Contact Current Rating	3A
Contact Termination	Crimp
Height	7.23mm
Length	58.41mm
Width	7.24mm
Radiation Hardening	No
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Not Applicable

1-102387-3 Product Details

1-102387-3 Overview

Receptacle packaging is included.The mounting type of the device is Free Hanging (In-Line).The product is packaged in a Bulk case.As a product of the AMPMODU Mod IV Series, it can be found in this category.Additionally, there are features like POLARIZED, SHROUDED, just to name a few.A number of features make it more powerful because of its Polarizing Key feature.Cable, Free Hanging represents the mounting point for the part.This memory's operating supply voltage is 250V.
