Name: B32520C1154K000
Brand: TDK Electronics Inc.
SKU: B32520C1154K000
Price: 0.13000 USD
Availability: InStock

new-10%

B32520C1154K000

Manufacturer part number:B32520C1154K000

Manufacturer:TDK Electronics Inc.

Description:B32520 0.15μF Film Capacitor ±10% Radial PC Pins 100V-DC 63V-AC Polyester, Polyethylene Terephthalate (PET), Metallized - Stacked

Case Package:SOT-23

Datasheet:B32520C1154K000 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	14 Weeks
Mounting Type	Through Hole
Package / Case	Radial
Surface Mount	NO
Terminal Shape	WIRE
Dielectric Material	Polyester, Polyethylene Terephthalate (PET), Metallized - Stacked
Operating Temperature	-55°C~125°C
Packaging	Bulk
Series	B32520
Size / Dimension	0.394Lx0.118W 10.00mmx3.00mm
Tolerance	±10%
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
Termination	PC Pins
ECCN Code	EAR99
Terminal Finish	Matte Tin (Sn)
Applications	Automotive; EMI, RFI Suppression
Additional Feature	RATED AC VOLTAGE (V): 400
HTS Code	8532.25.00.70
Capacitance	0.15μF
Voltage - Rated DC	100V
Terminal Pitch	7.5mm
Reach Compliance Code	unknown
Voltage - Rated AC	63V
Capacitor Type	FILM CAPACITOR
Lead Spacing	0.295 7.50mm
Rated (DC) Voltage (URdc)	100V
Size Code	3912
Rated (AC) Voltage (URac)	63V
Custom Capabilities	Special Lead Length Available On Request
Height Seated (Max)	0.315 8.00mm
Length	10mm
Width	3mm
RoHS Status	ROHS3 Compliant

B32520C1154K000 Product Details

B32520C1154K000 Overview

In order for systems to function, a rated (DC) voltage (URdc) of 100V is required internally.Its lead spacing is 0.295 7.50mm.System power requires an AC voltage rating of 63V (URac).A temperature of -55°C~125°C is suitable for operation of the device.
