TS2P5M20

  • TS2P5M20 - Receptacle, Male PinsCopper AlloyPanel Mount5 PositionsCrimp or Solder CupGoldElectroless NickelBulkKeyedThreaded
  • TS2P5M20 - Receptacle, Male PinsCopper AlloyPanel Mount5 PositionsCrimp or Solder CupGoldElectroless NickelBulkKeyedThreaded

TS2P5M20

TS2P5M20

Switchcraft Inc.

Receptacle, Male PinsCopper AlloyPanel Mount5 PositionsCrimp or Solder CupGoldElectroless NickelBulkKeyedThreaded

SOT-23

TS2P5M20 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 12 Weeks
Contact MaterialCopper Alloy
Mounting Type Panel Mount
Mounting FeatureBulkhead - Rear Side Nut
Shell Material Copper Alloy
Insert Material Liquid Crystal Polymer (LCP)
Operating Temperature-40°C~135°C
PackagingBulk
Series Dura-Twist™, TS
Part StatusActive
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp or Solder Cup
Connector Type Receptacle, Male Pins
Number of Positions 5
Color Silver
Applications Agriculture, Audio, General, Medical, Testing Equipment & Measurement
Voltage - Rated 125VAC/DC
Fastening TypeThreaded
Contact Finish - Mating Gold
Orientation Keyed
Shielding Shielded
Ingress ProtectionIP66/67/68 - Dust Tight, Water Resistant, Waterproof
Shell Finish Electroless Nickel
RoHS StatusRoHS Compliant
In-Stock:397 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$20.693909$20.693909
10$19.522555$195.22555
100$18.417505$1841.7505
500$17.375005$8687.5025
1000$16.391514$16391.514

TS2P5M20 Product Details

TS2P5M20 Overview


The packaging contains Receptacle, Male Pins.There is a Panel Mount mounting type for the device.This product is packaged in a case marked Bulk.Product number Dura-Twist™, TS belongs to the Dura-Twist™, TS Series.This device operates at a temperature of -40°C~135°C.

TS2P5M20 Features


Dura-Twist™, TS series


TS2P5M20 Applications


There are a lot of Switchcraft Inc.
TS2P5M20 Circular Connectors applications.


  • Medical technology
  • Military Technology
  • Measuring & Control Technology
  • Instrumentation
  • Automotive Electronics
  • Telecommunications
  • Data Technology
  • Blowers
  • Control panels
  • Electrical substations
