SC560EULTRT

Manufacturer part number:SC560EULTRT

Manufacturer:Semtech Corporation

Description:Enable, Power Good Fixed 0.4mm SC560 PMIC 8 8-UFQFN

Case Package:SOT-23

Datasheet:SC560EULTRT Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	4 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	8-UFQFN
Number of Pins	8
Operating Temperature	-40°C~85°C
Packaging	Tape & Reel (TR)
Published	2008
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	8
ECCN Code	EAR99
Terminal Finish	MATTE TIN
Packing Method	TAPE AND REEL
Terminal Position	QUAD
Terminal Form	NO LEAD
Peak Reflow Temperature (Cel)	260
Number of Functions	1
Terminal Pitch	0.4mm
Time@Peak Reflow Temperature-Max (s)	30
Base Part Number	SC560
Pin Count	8
Number of Outputs	2
Qualification Status	Not Qualified
Voltage - Input (Max)	5.5V
Output Voltage	2.85V
Output Type	Fixed
Output Configuration	Positive
Current - Output	300mA 300mA
Control Features	Enable, Power Good
Accuracy	3 %
Output Voltage 1	2.85V
Voltage - Output (Min/Fixed)	2.85V 2.85V
Number of Regulators	2
Min Input Voltage	2.5V
Protection Features	Over Temperature, Short Circuit, Under Voltage Lockout (UVLO)
Current - Quiescent (Iq)	100μA
Voltage Dropout (Max)	- -
PSRR	65dB ~ 40dB (1kHz)
Dropout Voltage	100mV
Dropout Voltage1-Nom	0.1V
Voltage Tolerance-Max	3%
Min Current Limit	350mA
Input Voltage Absolute-Max	6.5V
Output Voltage 2	2.85V
Length	1.5mm
Height Seated (Max)	0.6mm
Width	1.5mm
RoHS Status	RoHS Compliant
Lead Free	Lead Free

SC560EULTRT Product Details

SC560EULTRT Overview

This Voltage Regulator IC comes inTape & Reel (TR) packaging. This battery regulator is contained in a 8-UFQFN package. There are 8 terminations on the gadget. The IC chip's output type is Fixed. This electronic component implements 2 regulators. The Linear Voltage Regulator's mounting type is Surface Mount. The IC Regulator is set to operate at -40°C~85°C degrees. This regulator's output function is configured to be Positive. Its current output stands at 300mA 300mA. IC voltage regulator has a sum of 8 pins. To ensure prompt, sufficient performance, this part features 2 outputs in total. Its dropout voltage is 10 volts. The component's pin number remains 8. FYI, the basic part number for this IC regulator is SC560. The way of packing the voltage regulator IC is TAPE AND REEL.
