Name: TPS77525PWPRG4
Brand: Texas Instruments
SKU: TPS77525PWPRG4
Availability: InStock

new-10%

TPS77525PWPRG4

Manufacturer part number:TPS77525PWPRG4

Manufacturer:Texas Instruments

Description:Enable, Reset Fixed 0.65mm TPS77525 PMIC 20 20-PowerTSSOP (0.173, 4.40mm Width)

Case Package:SOT-23

Datasheet:TPS77525PWPRG4 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	20-PowerTSSOP (0.173, 4.40mm Width)
Number of Pins	20
Operating Temperature	-40°C~125°C
Packaging	Tape & Reel (TR)
Pbfree Code	yes
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	2 (1 Year)
Number of Terminations	20
ECCN Code	EAR99
Packing Method	TAPE AND REEL
Max Power Dissipation	7.2W
Terminal Position	DUAL
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Number of Functions	1
Terminal Pitch	0.65mm
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Base Part Number	TPS77525
Pin Count	20
Number of Outputs	1
Qualification Status	Not Qualified
Voltage - Input (Max)	10V
Output Voltage	2.5V
Output Type	Fixed
Output Configuration	Positive
Current - Output	500mA
Quiescent Current	87μA
Control Features	Enable, Reset
Output Voltage 1	2.5V
Number of Regulators	1
Min Input Voltage	2.7V
Protection Features	Over Current, Over Temperature, Reverse Polarity
Current - Quiescent (Iq)	125μA
PSRR	60dB (100Hz)
Dropout Voltage	169mV
Voltage Tolerance-Max	2%
Min Current Limit	1.2A
Input Bias Current	85μA
Length	6.5mm
Width	4.4mm
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

TPS77525PWPRG4 Product Details

TPS77525PWPRG4 Overview

This Voltage Regulator IC comes inTape & Reel (TR) packaging. This battery regulator is contained in a 20-PowerTSSOP (0.173, 4.40mm Width) package. There are 20 terminations on the gadget. The IC chip's output type is Fixed. This electronic component implements 1 regulators. The Linear Voltage Regulator's mounting type is Surface Mount. The IC Regulator is set to operate at -40°C~125°C degrees. This regulator's output function is configured to be Positive. Its current output stands at 500mA. IC voltage regulator has a sum of 20 pins. To ensure prompt, sufficient performance, this part features 1 outputs in total. Its dropout voltage is 10 volts. The component's pin number remains 20. FYI, the basic part number for this IC regulator is TPS77525. The way of packing the voltage regulator IC is TAPE AND REEL. It operates in the 87μA Quiescent Current state.
