Name: TST-115-04-G-D-RA
Brand: Samtec Inc.
SKU: TST-115-04-G-D-RA
Price: 7.56000 USD
Availability: InStock

new-10%

TST-115-04-G-D-RA

Manufacturer part number:TST-115-04-G-D-RA

Manufacturer:Samtec Inc.

Description:TST-115-04-G-D-RA datasheet pdf and Rectangular Connectors - Headers, Male Pins product details from Samtec Inc. stock available on our website

Case Package:SOT-23

Datasheet:TST-115-04-G-D-RA Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	3 Weeks
Contact Material	Phosphor Bronze
Mount	Through Hole
Mounting Type	Through Hole, Right Angle
Contact Shape	Square
Insulation Material	Polybutylene Terephthalate (PBT), Glass Filled
Housing Material	Polyester
Operating Temperature	-55°C~125°C
Packaging	Bulk
Published	2003
Series	Flex Stack, TST
JESD-609 Code	e4
Feature	Keying Slot
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Connector Type	Header
Number of Positions	30
Number of Rows	2
Gender	Male
Fastening Type	Push-Pull
Contact Finish - Mating	Gold
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Contact Type	Male Pin
Mixed Contacts	NO
Option	GENERAL PURPOSE
Current Rating (Amps)	3.4A per Contact
Orientation	Right Angle
Depth	12.32mm
Insulation Height	0.365 9.27mm
Style	Board to Cable/Wire
Number of Positions Loaded	All
Pitch - Mating	0.100 2.54mm
Insulation Color	Black
Row Spacing - Mating	0.100 (2.54mm)
Contact Length - Post	0.130 3.30mm
Shrouding	Shrouded - 4 Wall
Contact Length - Mating	0.250 6.35mm
Mating Information	MULTIPLE MATING PARTS AVAILABLE
UL Flammability Code	94V-0
Max Current Rating	3A
Height	9.27mm
Length	45.72mm
Contact Finish Thickness - Mating	10.0μin 0.25μm
Contact Finish Thickness - Post	3.00μin 0.076μm
Material Flammability Rating	UL94 V-0
REACH SVHC	No SVHC
RoHS Status	ROHS3 Compliant

TST-115-04-G-D-RA Product Details

TST-115-04-G-D-RA Overview

A Header packaging is included.There is a mounting type of Through Hole, Right Angle for this device.Packaged in a Bulk case.The product belongs to the Flex Stack, TST Series.Many aspects of its Keying Slot feature increase its effectiveness.Through Hole is used to mount the part.Devices operate at -55°C~125°C operating temperatures.
