Name: SQW-115-01-F-D-VS-P-TR
Brand: Samtec Inc.
SKU: SQW-115-01-F-D-VS-P-TR
Price: 4.94000 USD
Availability: InStock

new-10%

SQW-115-01-F-D-VS-P-TR

Manufacturer part number:SQW-115-01-F-D-VS-P-TR

Manufacturer:Samtec Inc.

Description:2 RowsReceptacleSolderPhosphor BronzeSurface MountTape & Reel (TR)GoldLiquid Crystal Polymer (LCP)30 PositionsForked

Case Package:SOT-23

Datasheet:SQW-115-01-F-D-VS-P-TR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	5 Weeks
Contact Material	Phosphor Bronze
Mount	Surface Mount
Mounting Type	Surface Mount
Contact Shape	Square
Insulation Material	Liquid Crystal Polymer (LCP)
Operating Temperature	-55°C~125°C
Packaging	Tape & Reel (TR)
Published	2013
Series	SQW
JESD-609 Code	e3
Feature	Pick and Place
Part Status	Active
Termination	Solder
ECCN Code	EAR99
Connector Type	Receptacle
Number of Positions	30
Number of Rows	2
Gender	Female
HTS Code	8536.69.40.40
Fastening Type	Push-Pull
Subcategory	Headers and Edge Type Connectors
Contact Finish - Mating	Gold
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Contact Type	Forked
Mixed Contacts	NO
Option	GENERAL PURPOSE
Current Rating (Amps)	3.8A per Contact
Total Number of Contacts	30
Orientation	Straight
Insulation Height	0.300 7.62mm
Style	Board to Board or Cable
Number of Positions Loaded	All
Pitch - Mating	0.079 2.00mm
Insulation Color	Black
Number of Conductors	ONE
Reference Standard	UL, CSA
Voltage - Rated AC	500V
Reliability	COMMERCIAL
Body Length or Diameter	1.193 inch
Row Spacing - Mating	0.079 (2.00mm)
Number Of PCB Rows	2
Contact Finish - Post	Tin
PCB Contact Pattern	RECTANGULAR
Body Breadth	0.157 inch
UL Flammability Code	94V-0
Body Depth	0.3 inch
Contact Resistance	10mOhm
Mating Contact Pitch	0.079 inch
Max Voltage Rating (AC)	500V
Max Current Rating	5A
Polarization Key	POLARIZED HOUSING
Durability	100 Cycles
Insertion Force-Max	.5004 N
Plating Thickness	3μin
Contact Finish Thickness - Mating	3.00μin 0.076μm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

SQW-115-01-F-D-VS-P-TR Product Details

SQW-115-01-F-D-VS-P-TR Overview

The product comes in a package of Receptacle.This device has a mounting type of Surface Mount.It's packaged in a Tape & Reel (TR) case.It belongs to the SQW Series of products.Its Pick and Place feature renders it more powerful in many ways.Part Surface Mount is mounted to the part.Device runs in -55°C~125°C operating temperature.
