Name: LSHM-120-02.5-L-DV-A-S-TR
Brand: Samtec Inc.
SKU: LSHM-120-02.5-L-DV-A-S-TR
Price: 7.73000 USD
Availability: InStock

new-10%

LSHM-120-02.5-L-DV-A-S-TR

Manufacturer part number:LSHM-120-02.5-L-DV-A-S-TR

Manufacturer:Samtec Inc.

Description:LSHM-120-02.5-L-DV-A-S-TR datasheet pdf and Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board) product details from Samtec Inc. stock available on our website

Case Package:SOT-23

Datasheet:LSHM-120-02.5-L-DV-A-S-TR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	3 Weeks
Contact Material	PHOSPHOR BRONZE
Mounting Type	Surface Mount
Insulation Material	LIQUID CRYSTAL POLYMER (LCP)
Mounting Option 1	LOCKING
Board Mounting Option	PEG
Packaging	Tape & Reel (TR)
Series	Razor Beam™ LSHM
JESD-609 Code	e3
Feature	Board Guide, Shielded
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
ECCN Code	EAR99
Connector Type	Self Mating, Non-Gendered
Number of Positions	40
Number of Rows	2
Subcategory	Headers and Edge Type Connectors
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	0.020 0.50mm
Total Number of Contacts	40
Number of Conductors	ONE
Reference Standard	UL
Contact Finish	Gold
Reliability	COMMERCIAL
Body Length or Diameter	0.589 inch
Number Of PCB Rows	2
PCB Contact Pattern	RECTANGULAR
Body Breadth	0.196 inch
Contact Gender	HERMAPHRODITIC
Operating Temperature (Min)	-55°C
UL Flammability Code	94V-0
Body Depth	0.156 inch
Rated Current (Signal)	2A
Contact Style	BELLOWED TYPE
Contact Resistance	15mOhm
Insulation Resistance	1000000000Ohm
Body/Shell Style	HERMAPHRODITIC
Polarization Key	POLARIZED HOUSING
Dielectric Withstanding Voltage	470VAC V
PCB Contact Row Spacing	3.7084 mm
Durability	100 Cycles
Contact Pattern	RECTANGULAR
Insulator Color	BLACK
Contact Finish Thickness	10.0μin 0.25μm
Plating Thickness	10μin
Height Above Board	0.156 3.96mm
Stack Height (Mating)	5mm 5.5mm 6.5mm 8.5mm
RoHS Status	ROHS3 Compliant

LSHM-120-02.5-L-DV-A-S-TR Product Details

LSHM-120-02.5-L-DV-A-S-TR Overview

The product is packaged in Self Mating, Non-Gendered.A Tape & Reel (TR) case is used for packaging.This device's mounting type is Surface Mount.This product is part of the Razor Beam? LSHM Series.In operation, it is possible to ensure that Board Guide, Shielded is maintained.
