Name: FX6-40S-0.8SV2(71)
Brand: Hirose Electric Co Ltd
SKU: FX6-40S-0.8SV2(71)
Price: 4.49000 USD
Availability: InStock

new-10%

FX6-40S-0.8SV2(71)

Manufacturer part number:FX6-40S-0.8SV2(71)

Manufacturer:Hirose Electric Co Ltd

Description:FX6-40S-0.8SV2(71) datasheet pdf and Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board) product details from Hirose Electric Co Ltd stock available on our website

Case Package:SOT-23

Datasheet:FX6-40S-0.8SV2(71) Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	12 Weeks
Contact Material	Bronze
Mount	Surface Mount
Mounting Type	Surface Mount
Housing Material	Polyphenylene
Packaging	Tube
Series	FX6
JESD-609 Code	e3
Feature	Board Guide
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	SMD/SMT
ECCN Code	EAR99
Connector Type	Receptacle, Center Strip Contacts
Number of Positions	40
Number of Rows	2
Gender	Receptacle
Voltage - Rated	100V
Subcategory	Headers and Edge Type Connectors
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	0.031 0.80mm
Total Number of Contacts	40
Orientation	Straight
Current Rating	500mA
Number of Conductors	ONE
Reference Standard	UL
Contact Finish	Gold
Reliability	COMMERCIAL
Body Length or Diameter	0.937 inch
Number Of PCB Rows	2
Lead Pitch	800μm
PCB Contact Pattern	RECTANGULAR
Operating Temperature (Max)	85°C
Operating Temperature (Min)	-55°C
UL Flammability Code	94V-0
Housing Color	Brown
Rated Current (Signal)	0.5A
Contact Style	BELLOWED TYPE
Contact Resistance	50mOhm
Insulation Resistance	100000000Ohm
Row Spacing	2.7 mm
Polarization Key	POLARIZED HOUSING
Contact Pattern	RECTANGULAR
Plating Thickness	4μin
Height Above Board	0.236 6.00mm
Stack Height (Mating)	7mm 8mm 9mm
Radiation Hardening	No
REACH SVHC	No SVHC
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

FX6-40S-0.8SV2(71) Product Details

FX6-40S-0.8SV2(71) Overview

This product is packaged in a Receptacle, Center Strip Contacts box.It is necessary to use a Tube case for packaging the product.The device's mounting type is Surface Mount.FX6 Series product.When operating, it is possible to ensure that Board Guide is maintained.This part requires a Surface Mount socket for mounting.
