Name: LSH-050-01-G-D-A-K-TR
Brand: Samtec Inc.
SKU: LSH-050-01-G-D-A-K-TR
Price: 11.42000 USD
Availability: InStock

new

LSH-050-01-G-D-A-K-TR

Manufacturer part number:LSH-050-01-G-D-A-K-TR

Manufacturer:Samtec Inc.

Description:LSH-050-01-G-D-A-K-TR datasheet pdf and Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board) product details from Samtec Inc. stock available on our website

Case Package:SOT-23

Datasheet:LSH-050-01-G-D-A-K-TR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	3 Weeks
Contact Material	Copper
Mounting Type	Surface Mount
Housing Material	Polymer
Board Mounting Option	PEG
Packaging	Tape & Reel (TR)
Published	2015
Series	LSH
JESD-609 Code	e4
Feature	Board Guide, Pick and Place
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
ECCN Code	EAR99
Connector Type	Receptacle, Center Strip Contacts
Number of Positions	100
Max Operating Temperature	125°C
Min Operating Temperature	-55°C
Number of Rows	2
Gender	Female
HTS Code	8536.69.40.40
Subcategory	Headers and Edge Type Connectors
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	0.020 0.50mm
Total Number of Contacts	100
Orientation	Straight
Depth	6.5mm
Number of Conductors	ONE
Contact Finish	Gold
Reliability	COMMERCIAL
Number Of PCB Rows	2
Mating Information	MULTIPLE MATING PARTS AVAILABLE
Body/Shell Style	SOCKET
Polarization Key	POLARIZED KEY
Contact Pattern	RECTANGULAR
Mating Contact Row Spacing	0.14 inch
Insulator Color	BLACK
Length	30.06mm
Contact Finish Thickness	10.0μin 0.25μm
Plating Thickness	10μin
Height Above Board	0.075 1.90mm
Stack Height (Mating)	2.31mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant

LSH-050-01-G-D-A-K-TR Product Details

LSH-050-01-G-D-A-K-TR Overview

It comes in a Receptacle, Center Strip Contacts package.Packaging for the product is carried out via a Tape & Reel (TR) case.This device is mounted in the Surface Mount position.A member of the LSH Series.When operating, it is possible to ensure that Board Guide, Pick and Place is maintained.When the temperature is below 125°C, it is best to use it.A minimum temperature of -55°C is needed for this device.
