Name: AXT640124
Brand: Panasonic Electric Works
SKU: AXT640124
Price: 1.87000 USD
Availability: InStock

new-10%

AXT640124

Manufacturer part number:AXT640124

Manufacturer:Panasonic Electric Works

Description:Header, Center Strip Contacts Tape & Reel (TR) 2 Rows 0.016 0.40mm Surface Mount 40 Positions F4S Gold Solder Copper

Case Package:SOT-23

Datasheet:AXT640124 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	10 Weeks
Contact Material	Copper
Mount	Surface Mount
Mounting Type	Surface Mount
Housing Material	Polymer
Packaging	Tape & Reel (TR)
Published	2008
Series	F4S
JESD-609 Code	e4
Feature	Solder Retention
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
ECCN Code	EAR99
Connector Type	Header, Center Strip Contacts
Number of Positions	40
Max Operating Temperature	85°C
Min Operating Temperature	-55°C
Number of Rows	2
Voltage - Rated	60V
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	0.016 0.40mm
Total Number of Contacts	40
Orientation	Straight
Current Rating	300mA
Contact Finish	Gold
Mating Information	MULTIPLE MATING PARTS AVAILABLE
Contact Gender	MALE
UL Flammability Code	94V-0
Contact Resistance	90mOhm
Max Voltage Rating (DC)	6.06kV
Height Above Board	0.033 0.84mm
Stack Height (Mating)	1mm
Radiation Hardening	No
RoHS Status	RoHS Compliant
Lead Free	Lead Free

AXT640124 Product Details

AXT640124 Overview

It comes in Header, Center Strip Contacts packaging.In order to package the product, a Tape & Reel (TR) case is used.The device's mounting type is Surface Mount.It belongs to the F4S Series of products.When operating, it is possible to ensure that Solder Retention is maintained.It is necessary to use a Surface Mount socket in order to mount this part.It's best to use it when the temperature is below 85°C.This device must operate at a minimum temperature of -55°C.
