Name: ESW-113-12-S-D
Brand: Samtec Inc.
SKU: ESW-113-12-S-D
Price: 8.22000 USD
Availability: InStock

new-10%

ESW-113-12-S-D

Manufacturer part number:ESW-113-12-S-D

Manufacturer:Samtec Inc.

Description:2 RowsElevated SocketSolderPhosphor BronzeThrough HoleTubeGoldLiquid Crystal Polymer (LCP)26 PositionsForked

Case Package:SOT-23

Datasheet:ESW-113-12-S-D Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	3 Weeks
Contact Material	Phosphor Bronze
Mount	Through Hole
Mounting Type	Through Hole
Contact Shape	Square
Insulation Material	Liquid Crystal Polymer (LCP)
Housing Material	Polyester
Operating Temperature	-55°C~125°C
Packaging	Tube
Published	2010
Series	ESW
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
ECCN Code	EAR99
Connector Type	Elevated Socket
Number of Positions	26
Number of Rows	2
Gender	Receptacle
Voltage - Rated	550VAC
Additional Feature	TIGER BUY CONTACT
HTS Code	8536.69.40.40
Fastening Type	Push-Pull
Subcategory	Headers and Edge Type Connectors
Contact Finish - Mating	Gold
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Contact Type	Forked
Mixed Contacts	NO
Option	GENERAL PURPOSE
Current Rating (Amps)	5.2A per Contact
Orientation	Straight
Depth	4.95mm
Insulation Height	0.435 11.05mm
Style	Board to Board
Number of Positions Loaded	All
Pitch - Mating	0.100 2.54mm
Number of Conductors	ONE
Reference Standard	UL, CSA
Reliability	COMMERCIAL
Row Spacing - Mating	0.100 (2.54mm)
Contact Length - Post	0.090 2.29mm
Number Of PCB Rows	2
Contact Finish - Post	Tin
PCB Contact Pattern	RECTANGULAR
Body Breadth	0.195 inch
Housing Color	Black
Contact Resistance	10mOhm
Mating Contact Pitch	0.1 inch
Max Voltage Rating (AC)	550V
Max Current Rating	3A
Insertion Force-Max	1.668 N
Withdrawl Force-Min	1.39 N
Length	33.53mm
Plating Thickness	30μin
Contact Finish Thickness - Mating	30.0μin 0.76μm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

ESW-113-12-S-D Product Details

ESW-113-12-S-D Overview

It comes in a Elevated Socket package.Through Hole is the mount type.Packaging for the product is carried out via a Tube case.This product is in the ESW Series.Additionally, there are other features such as TIGER BUY CONTACT.Through Hole represents the mounting point for the part.Operating temperature is -55°C~125°C.
