Name: ESW-112-12-G-D
Brand: Samtec Inc.
SKU: ESW-112-12-G-D
Price: 7.26000 USD
Availability: InStock

new-10%

ESW-112-12-G-D

Manufacturer part number:ESW-112-12-G-D

Manufacturer:Samtec Inc.

Description:2 RowsElevated SocketSolderPhosphor BronzeThrough HoleTubeGoldLiquid Crystal Polymer (LCP)24 PositionsForked

Case Package:SOT-23

Datasheet:ESW-112-12-G-D Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	3 Weeks
Contact Material	Phosphor Bronze
Mount	Through Hole
Mounting Type	Through Hole
Contact Shape	Square
Insulation Material	Liquid Crystal Polymer (LCP)
Operating Temperature	-55°C~125°C
Packaging	Tube
Published	2015
Series	ESW
JESD-609 Code	e4
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
ECCN Code	EAR99
Connector Type	Elevated Socket
Number of Positions	24
Number of Rows	2
Gender	Receptacle
Voltage - Rated	550VAC
Additional Feature	TIGER BUY CONTACT
HTS Code	8536.69.40.40
Fastening Type	Push-Pull
Subcategory	Headers and Edge Type Connectors
Contact Finish - Mating	Gold
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Contact Type	Forked
Mixed Contacts	NO
Option	GENERAL PURPOSE
Current Rating (Amps)	5.2A per Contact
Insulation Height	0.435 11.05mm
Style	Board to Board
Number of Positions Loaded	All
Pitch - Mating	0.100 2.54mm
Insulation Color	Black
Number of Conductors	ONE
Reference Standard	UL, CSA
Reliability	COMMERCIAL
Row Spacing - Mating	0.100 (2.54mm)
Contact Length - Post	0.090 2.29mm
Number Of PCB Rows	2
PCB Contact Pattern	RECTANGULAR
Mating Information	MULTIPLE MATING PARTS AVAILABLE
Body Breadth	0.195 inch
Body Depth	0.435 inch
Contact Resistance	10mOhm
Mating Contact Pitch	0.1 inch
Polarization Key	POLARIZED HOUSING
Contact Finish Thickness - Mating	20.0μin 0.51μm
Contact Finish Thickness - Post	3.00μin 0.076μm
Length - Termination	0.09 inch
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	ROHS3 Compliant

ESW-112-12-G-D Product Details

ESW-112-12-G-D Overview

Packaging is Elevated Socket.This device's mounting type is Through Hole.Packaging is performed using a Tube case.This product is from the ESW Series.Other features include TIGER BUY CONTACT, to name just a few.There's a Through Hole mount on the part.Operating temperature is -55°C~125°C.
