Name: ERF8-040-07.0-S-DV-K-TR
Brand: Samtec Inc.
SKU: ERF8-040-07.0-S-DV-K-TR
Price: 10.62000 USD
Availability: InStock

new

ERF8-040-07.0-S-DV-K-TR

Manufacturer part number:ERF8-040-07.0-S-DV-K-TR

Manufacturer:Samtec Inc.

Description:Socket, Outer Shroud Contacts Tape & Reel (TR) 2 Rows 0.031 0.80mm Surface Mount 80 Positions Edge Rate™ ERF8 Gold Solder BERYLLIUM COPPER

Case Package:SOT-23

Datasheet:ERF8-040-07.0-S-DV-K-TR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	6 Weeks
Contact Material	BERYLLIUM COPPER
Mounting Type	Surface Mount
Insulation Material	LIQUID CRYSTAL POLYMER (LCP)
Mounting Option 1	LOCKING
Packaging	Tape & Reel (TR)
Series	Edge Rate™ ERF8
JESD-609 Code	e3
Feature	Board Guide, Pick and Place
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Connector Type	Socket, Outer Shroud Contacts
Number of Positions	80
Number of Rows	2
Gender	Receptacle
Additional Feature	EDGE RATE CONTACT, E.L.P
Subcategory	Headers and Edge Type Connectors
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	0.031 0.80mm
Total Number of Contacts	80
Number of Conductors	ONE
Reference Standard	UL
Contact Finish	Gold
Reliability	COMMERCIAL
Body Length or Diameter	1.496 inch
Number Of PCB Rows	2
PCB Contact Pattern	RECTANGULAR
Mating Information	MULTIPLE MATING PARTS AVAILABLE
Operating Temperature (Min)	-55°C
Contact Style	BELLOWED TYPE
Polarization Key	POLARIZED HOUSING
PCB Contact Row Spacing	4.4958 mm
Contact Pattern	RECTANGULAR
Insulator Color	BLACK
Contact Finish Thickness	30.0μin 0.76μm
Plating Thickness	30μin
Height Above Board	0.285 7.24mm
Stack Height (Mating)	9mm 12mm 15mm 16mm 22mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant

ERF8-040-07.0-S-DV-K-TR Product Details

ERF8-040-07.0-S-DV-K-TR Overview

Packaging for this item is Socket, Outer Shroud Contacts.It is necessary to use a Tape & Reel (TR) case for packaging the product.There is a mounting type of Surface Mount for this device.This product is part of the Edge Rate™ ERF8 Series.In operation, it is possible to ensure that Board Guide, Pick and Place is maintained.Moreover, there are a number of other features, including EDGE RATE CONTACT, E.L.P, to name just a few.
