Name: CLP-120-02-FM-D-K-TR
Brand: Samtec Inc.
SKU: CLP-120-02-FM-D-K-TR
Price: 3.71000 USD
Availability: InStock

new-10%

CLP-120-02-FM-D-K-TR

Manufacturer part number:CLP-120-02-FM-D-K-TR

Manufacturer:Samtec Inc.

Description:2 RowsReceptacleSolderPhosphor BronzeSurface MountTape & Reel (TR)GoldLiquid Crystal Polymer (LCP)40 PositionsFemale Socket

Case Package:SOT-23

Datasheet:CLP-120-02-FM-D-K-TR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	3 Weeks
Contact Material	Phosphor Bronze
Mounting Type	Surface Mount
Contact Shape	Square
Insulation Material	Liquid Crystal Polymer (LCP)
Operating Temperature	-55°C~125°C
Packaging	Tape & Reel (TR)
Series	CLP
JESD-609 Code	e3
Feature	Pick and Place
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Connector Type	Receptacle
Number of Positions	40
Number of Rows	2
Gender	Female
Voltage - Rated	240VAC 330VDC
Additional Feature	LOW PROFILE
Fastening Type	Push-Pull
Subcategory	Headers and Edge Type Connectors
Contact Finish - Mating	Gold
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Contact Type	Female Socket
Mixed Contacts	NO
Option	GENERAL PURPOSE
Current Rating (Amps)	3.3A per Contact
Total Number of Contacts	40
Insulation Height	0.084 2.14mm
Style	Board to Board
Number of Positions Loaded	All
Pitch - Mating	0.050 1.27mm
Insulation Color	Black
Number of Conductors	ONE
Reliability	COMMERCIAL
Body Length or Diameter	1.017 inch
Row Spacing - Mating	0.050 (1.27mm)
Number Of PCB Rows	2
Contact Finish - Post	Tin
PCB Contact Pattern	RECTANGULAR
UL Flammability Code	94V-0
Body Depth	0.09 inch
Mating Contact Pitch	0.05 inch
Plating Thickness	3μin
Contact Finish Thickness - Mating	3.00μin 0.076μm
Material Flammability Rating	UL94 V-0
RoHS Status	ROHS3 Compliant

CLP-120-02-FM-D-K-TR Product Details

CLP-120-02-FM-D-K-TR Overview

Packaging is Receptacle.There is a mounting type of Surface Mount for this device.It has been determined that a Tape & Reel (TR) case is necessary to package the product.Product number CLP belongs to the CLP Series.To name a few, there is also LOW PROFILE.This feature renders it more powerful in a number of ways because of its Pick and Place feature.-55°C~125°C Operating Temperature is what the device runs at.
