8T49N285-998NLGI Overview
Clock generator is packaged in the way of Tray. Clock PLL is embedded in the 56-VFQFN Exposed Pad package. HCSL, LVCMOS, LVDSM, LVHSTL, LVPECL, Crystal is designed for clock generator's input. 1 circuits are used to achieve clock PLL's superior flexibility. 1GHz is the maximal value for normal operation. PLL clock is mounted in the way of Surface Mount. Clock generators should operate with the voltage supply of 2.375V~3.465V. The temperature should be set at -40°C~85°C to ensure reliable performance. HSCL, LVCMOS, LVDS, LVPECL is designed for clock generator's output. According to the base part number, its related parts can be founded. This clock generator is a member of FemtoClock® NG series.
8T49N285-998NLGI Features
Available in the 56-VFQFN Exposed Pad
8T49N285-998NLGI Applications
There are a lot of Renesas Electronics America Inc.
8T49N285-998NLGI Clock Generators applications.
- Wireless infrastructure
- Instrument
- Automatic test equipment
- Wide area power system
- Digital circuits
- Wireless base station for LTE, LTE-advanced
- Picocells, femtocells and small cells
- Sampling clocks for ADC and DAC
- 1 Gigabit Ethernet
- 10 Gigabit Ethernet
