5L35021-000NDGI Overview
It is packaged using the Tray method since it is a clock IC. Embedded in the 20-VFQFN Exposed Pad package is this Clock PLL. It is designed that the Clock PLL's input should be Clock, Crystal. A total of 3 circuits are implemented to access the full performance of the electrical part. Using this clock-based frequency synthesizer, you can achieve a maximum frequency of 250MHz. Because of the Surface Mount, clock PLL can be easily mounted on the panel. As long as you provide 1.71V~1.89V supply voltage, it will work. Using the test statistics, we estimate that the ambient temperature should be -40°C~85°C TA. The RF synthesizer is compatible with LP-HCSL, LVCMOS logic levels. An electrical part such as this one can be classified as a Clock Generator component. An electronic part belonging to the VersaClock® series is being used here.
5L35021-000NDGI Features
Available in the 20-VFQFN Exposed Pad
5L35021-000NDGI Applications
There are a lot of Renesas Electronics America Inc.
5L35021-000NDGI Clock Generators applications.
- 1 Gigabit Ethernet
- 10 Gigabit Ethernet
- FPGA and processor clocks
- Line cards used in telephone exchange
- Fiber Channel
- PCI express cards
- Infotainment systems
- Medical equipment
- Multi-function printers
- Media broadcast servers
