Name: R5F100ACGSP#V0
Brand: Renesas Electronics America
SKU: R5F100ACGSP#V0
Availability: InStock

new-10%

R5F100ACGSP#V0

Manufacturer part number:R5F100ACGSP#V0

Manufacturer:Renesas Electronics America

Description:32KB 32K x 8 FLASH RL78 16-Bit Microcontroller RL78/G13 Series R5F100 30 Pin 32MHz 3V 30-LSSOP (0.240, 6.10mm Width)

Case Package:SOT-23

Datasheet:R5F100ACGSP#V0 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	24 Weeks
Mounting Type	Surface Mount
Package / Case	30-LSSOP (0.240, 6.10mm Width)
Surface Mount	YES
Number of Pins	30
Operating Temperature	-40°C~105°C TA
Packaging	Tray
Series	RL78/G13
Published	2015
Pbfree Code	yes
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	30
Additional Feature	IT ALSO OPERATES AT 16MHZ @2.4V MIN SUPPLY
HTS Code	8542.31.00.01
Terminal Position	DUAL
Terminal Form	GULL WING
Supply Voltage	3V
Terminal Pitch	0.65mm
Frequency	32MHz
Base Part Number	R5F100
Pin Count	30
Supply Voltage-Max (Vsup)	5.5V
Supply Voltage-Min (Vsup)	2.7V
Interface	I2C, LIN, UART, USART
Memory Size	32kB
Oscillator Type	Internal
Number of I/O	21
RAM Size	2K x 8
Voltage - Supply (Vcc/Vdd)	1.6V~5.5V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER
Core Processor	RL78
Peripherals	DMA, LVD, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	16-Bit
Program Memory Size	32KB 32K x 8
Connectivity	CSI, I2C, LINbus, UART/USART
Bit Size	16
Data Converter	A/D 8x8/10b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	YES
Data Bus Width	16b
PWM Channels	YES
DAC Channels	NO
Number of Timers/Counters	13
ROM (words)	32768
EEPROM Size	4K x 8
On Chip Program ROM Width	8
Number of Programmable I/O	26
Length	9.85mm
Height Seated (Max)	1.4mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant

R5F100ACGSP#V0 Product Details

R5F100ACGSP#V0 Overview

It comes in a 30-LSSOP (0.240, 6.10mm Width) package. It has a number of 21I/Os. The Mounting Type of the device is Surface Mount. It is based on the 16-Bit. The It?ˉs Program Memory Type is FLASH. The device runs in -40??C~105??C TA Operating Temperature. It runs in RL78/G13 Series.

R5F100ACGSP#V0 Features

RL78/G13 series
Base part number of R5F100
Additional features of IT ALSO OPERATES AT 16MHZ @2.4V MIN SUPPLY
30 Terminals
Based on the 16-Bit
Comes with 30 Pins

R5F100ACGSP#V0 Applications

There are a lot of Renesas Electronics America R5F100ACGSP#V0 Microcontroller applications. R5F100ACGSP#V0 MCU is usually applied for Measurement and control field, Consumer electronics products, Network communication, mobile communication, Office automation equipment and computer peripherals, Industrial control Instrumentation and process control, Agriculture, transportation, Navigation control, Network application, Metering & measurement, Day to day life, Safety, Medical instruments and Automobile industry.
