Name: NP60N03SUG-E1-AY
Brand: Renesas Electronics America
SKU: NP60N03SUG-E1-AY
Availability: InStock

new-10%

NP60N03SUG-E1-AY

Manufacturer part number:NP60N03SUG-E1-AY

Manufacturer:Renesas Electronics America

Description:MOSFET N-CH 30V 60A TO-252

Case Package:SOT-23

Datasheet:NP60N03SUG-E1-AY Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	TO-252-3, DPak (2 Leads + Tab), SC-63
Number of Pins	3
Transistor Element Material	SILICON
Operating Temperature	175°C TJ
Packaging	Tape & Reel (TR)
Published	2008
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
ECCN Code	EAR99
Subcategory	FET General Purpose Power
Technology	MOSFET (Metal Oxide)
Terminal Position	SINGLE
Terminal Form	GULL WING
Pin Count	3
JESD-30 Code	R-PSSO-G2
Number of Elements	1
Configuration	SINGLE WITH BUILT-IN DIODE
Power Dissipation-Max	1.2W Ta 105W Tc
Operating Mode	ENHANCEMENT MODE
Case Connection	DRAIN
Turn On Delay Time	32 ns
FET Type	N-Channel
Transistor Application	SWITCHING
Rds On (Max) @ Id, Vgs	3.8m Ω @ 30A, 10V
Vgs(th) (Max) @ Id	4V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds	7500pF @ 25V
Current - Continuous Drain (Id) @ 25°C	60A Tc
Gate Charge (Qg) (Max) @ Vgs	135nC @ 10V
Rise Time	20ns
Drain to Source Voltage (Vdss)	30V
Drive Voltage (Max Rds On,Min Rds On)	10V
Vgs (Max)	±20V
Fall Time (Typ)	13 ns
Turn-Off Delay Time	64 ns
Continuous Drain Current (ID)	60A
JEDEC-95 Code	TO-252AA
Gate to Source Voltage (Vgs)	20V
Pulsed Drain Current-Max (IDM)	240A
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free
