Name: 851-83-032-10-001101
Brand: Preci-Dip
SKU: 851-83-032-10-001101
Price: 5.00000 USD
Availability: InStock

new-10%

851-83-032-10-001101

Manufacturer part number:851-83-032-10-001101

Manufacturer:Preci-Dip

Description:1 RowsSocketSolderBeryllium CopperThrough HoleBulkGoldPolycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled32 PositionsFemale Socket

Case Package:SOT-23

Datasheet:851-83-032-10-001101 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	10 Weeks
Contact Material	Beryllium Copper
Mount	Through Hole
Mounting Type	Through Hole
Contact Shape	Circular
Insulation Material	Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
Operating Temperature	-55°C~125°C
Packaging	Bulk
Published	2012
Series	851
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Connector Type	Socket
Number of Positions	32
Number of Rows	1
Fastening Type	Push-Pull
Subcategory	Headers and Edge Type Connectors
Contact Finish - Mating	Gold
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Contact Type	Female Socket
Mixed Contacts	NO
Option	GENERAL PURPOSE
Current Rating (Amps)	1A
Insulation Height	0.161 4.10mm
Style	Board to Board
Number of Positions Loaded	All
Pitch - Mating	0.050 1.27mm
Insulation Color	Black
Number of Conductors	ONE
Reference Standard	UL
Reliability	COMMERCIAL
Contact Length - Post	0.091 2.30mm
Contact Finish - Post	Tin
Body Breadth	0.087 inch
UL Flammability Code	94V-0
Contact Resistance	20mOhm
Mating Contact Pitch	0.05 inch
Dielectric Withstanding Voltage	700VAC V
Durability	500 Cycles
Insertion Force-Max	.5004 N
Plating Thickness	29μin
Contact Finish Thickness - Mating	29.5μin 0.75μm
Material Flammability Rating	UL94 V-0
RoHS Status	ROHS3 Compliant

851-83-032-10-001101 Product Details

851-83-032-10-001101 Overview

You get it in Socket packaging.This device has a Through Hole mounting type.Packaged in a Bulk case.This product is from the 851 Series.In this case, Through Hole mounts the part.This device runs at -55°C~125°C operating temperature.
