Name: LNK625DG
Brand: Power Integrations
SKU: LNK625DG
Availability: InStock

new-10%

LNK625DG

Manufacturer part number:LNK625DG

Manufacturer:Power Integrations

Description:7 Terminations8 Pin AC to DC power converterLinkSwitch?-CV Series 3 OutputsMin 85V VMax 265V V

Case Package:SOT-23

Datasheet:LNK625DG Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	6 Weeks
Mounting Type	Surface Mount
Package / Case	8-SOIC (0.154, 3.90mm Width), 7 Leads
Surface Mount	YES
Number of Pins	8
Operating Temperature	-40°C~150°C TJ
Packaging	Tube
Published	2009
Series	LinkSwitch®-CV
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Discontinued
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	7
Terminal Finish	Matte Tin (Sn)
Power Rating	13.5W
Max Power Dissipation	13.5W
Terminal Position	DUAL
Terminal Form	GULL WING
Number of Functions	1
Supply Voltage	230V
Terminal Pitch	1.27mm
Frequency	100kHz
Pin Count	8/7
JESD-30 Code	R-PDSO-G7
Number of Outputs	3
Output Voltage	700V
Voltage	700V
Analog IC - Other Type	ANALOG CIRCUIT
Operating Supply Current	480μA
Power Dissipation	6.5W
Output Current	790mA
Output Power	8W
Topology	Flyback
Min Input Voltage	85V
Max Input Voltage	265V
Internal Switch(s)	Yes
Fault Protection	Current Limiting, Open Loop, Over Temperature, Short Circuit
Max Duty Cycle	54 %
Max Supply Voltage (AC)	265V
Duty Cycle	54%
Output Isolation	Isolated
Voltage - Breakdown	725V
Min Input Voltage (AC)	85V
Max Input Voltage (AC)	265V
Min Supply Voltage (AC)	85V
Height Seated (Max)	1.75mm
Length	4.9mm
Radiation Hardening	No
REACH SVHC	No SVHC
RoHS Status	RoHS Compliant

LNK625DG Product Details

LNK625DG Overview

A ac to dc converter of the package 8-SOIC (0.154, 3.90mm Width), 7 Leads contains the ac to dc converter.There is a AC/DC power converter of Tube available.Surface Mount is mounted in the way of this AC/DC converter.It is necessary to operate the ac dc converter at a temperature of -40°C~150°C TJ °C in order for it to perform properly.A ANALOG CIRCUIT analog integrated circuit is used in this AC DC converter.Total terminations are 7 .There are 8 pins on the ac/dc converter.There are a total of 8/7 pins on the ac-dc converter.It is a member of LinkSwitch?-CV manufacturer family.The number of outputs to run is 3 .There is 790mA output current set.In this AC to DC transformer, the output voltage is 700V .The power AC DC is capable of high efficiency when operated at a frequency of 100kHz .In the following link, you will find the REACH SVHC standard: No SVHC .Input voltage for the AC to DC converter is available under 265V .Coverters generate 8W in terms of output power.An input voltage of less than 85V volts can be used with the AC to DC inverter.There should be no less than 85V voltage across the converter.It is possible to supply 265V voltage across the converter.At all times, this AC to DC converter should be set to 230V .An input voltage (AC) should be applied to the AC to DC power converter that falls below 265V volts.
