Name: 1988147
Brand: Phoenix Contact
SKU: 1988147
Price: 4.26000 USD
Availability: InStock

new-10%

1988147

Manufacturer part number:1988147

Manufacturer:Phoenix Contact

Description:0.295 7.50mm Green Bulk Polyamide (PA), Nylon Through Hole Horizontal with Board Screw - Leaf Spring, Wire Guard 1 Levels 12-20 AWG COMBICON PT

Case Package:SOT-23

Datasheet:1988147 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	8 Weeks
Contact Material	Tin
Mount	Through Hole
Mounting Type	Through Hole
Material	Nylon
Housing Material	Polyamide (PA), Nylon
Weight	311.844754g
Packaging	Bulk
Series	COMBICON PT
Published	2005
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Screw
ECCN Code	EAR99
Color	Green
Number of Rows	1
Voltage - Rated	500V
Additional Feature	PA, UL 94V-0
Pitch	0.295 7.50mm
Current Rating	32A
Wire Gauge	12-20 AWG
Voltage	300V
Number of Levels	1
Current	20A
Wire Gauge (Max)	20 AWG
Wire Gauge (Min)	12 AWG
Wire/Cable Gauge	10 AWG
Number of Decks	1
Terminal and Terminal Block Type	BARRIER STRIP TERMINAL BLOCK
Torque - Screw	0.45-0.5 Nm (3.9-4.4 Lb-In)
Number of Ways	6
Safety Approval	UL
Mating Orientation	Horizontal with Board
Wire Termination	Screw - Leaf Spring, Wire Guard
Screw Thread	M3
Number of Positions Per Level	6
Wire Cross Section	4 mm2
Height	13.5mm
Length	9mm
Width	45mm
RoHS Status	RoHS Compliant

1988147 Product Details

1988147 Overview

There is a Through Hole mounting type for the device.This product is packaged in a case marked Bulk.Product number COMBICON PT belongs to the COMBICON PT Series.Further, there are features such as PA, UL 94V-0, to name only a few.There is a Through Hole mount on the part.
