Name: 1909427
Brand: Phoenix Contact
SKU: 1909427
Price: 5.22000 USD
Availability: InStock

new-10%

1909427

Manufacturer part number:1909427

Manufacturer:Phoenix Contact

Description:1909427 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Phoenix Contact stock available on our website

Case Package:SOT-23

Datasheet:1909427 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	4 Weeks
Mount	Free Hanging
Mounting Type	Free Hanging (In-Line)
Material	Polyamide, Tin
Housing Material	Polyamide (PA), Nylon
Weight	7.490001g
Packaging	Bulk
Published	2010
Series	COMBICON FKCT
Feature	Mating Flange
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Screwless
ECCN Code	EAR99
Type	Plug, Female Sockets
Color	Green
Number of Rows	1
Gender	Female
Voltage - Rated	250V
Pitch	0.197 5.00mm
Insulation Height	0.591 15.00mm
Current Rating	12A
Termination Style	Screwless - Leg Spring, Push-In Spring
Voltage	300V
Number of Levels	1
Current	10A
Wire Gauge (Max)	26 AWG
Wire Gauge (Min)	12 AWG
Contact Mating Finish	Tin
Number of Decks	1
Wire Gauge or Range - AWG	12-26 AWG
Voltage - IEC	630V
Number of Ways	4
Safety Approval	UL
Plug Wire Entry	180°
Wire Gauge or Range - mm²	0.2-2.5mm2
Wire Strip Length	10mm
Current - IEC	12A
Number of Positions Per Level	4
Wire Cross Section	2.5 mm2
Fastening Method	SPRING LOADED
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0

1909427 Product Details

1909427 Overview

This device has a mounting type of Free Hanging (In-Line).It has been determined that a Bulk case is necessary to package the product.The product is a member of the COMBICON FKCT Series.Its Mating Flange feature renders it more powerful in many ways.Mounting of the part is based on Free Hanging.There are a number of benefits that this part has in common with other Plug, Female Sockets products.
