1857977

1857977

1857977

Phoenix Contact

1857977 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Phoenix Contact stock available on our website

SOT-23

1857977 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 7 Weeks
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Polyamide (PA), Nylon
Weight 102.999998g
PackagingBulk
Published 2011
Series COMBICON IMC
Pbfree Code yes
Part StatusActive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Screw
Type Plug, Male Pins
Number of Positions 11
Color Green
Number of Rows 1
Voltage - Rated 160V
Additional FeaturePA, 94V-0
HTS Code8536.69.40.40
Pitch 0.150 3.81mm
Insulation Height 0.437 11.10mm
Reach Compliance Code unknown
Current Rating8A
Termination Style Screw - Rising Cage Clamp
Voltage 300V
Number of Levels 1
Current 8A
Wire Gauge (Max) 16 AWG
Wire Gauge (Min) 28 AWG
Contact Mating Finish Tin
Number of Decks 1
Wire Gauge or Range - AWG 14-30 AWG
Voltage - IEC 320V
Torque - Screw 0.22-0.25 Nm (1.9-2.2 Lb-In)
Number of Ways 11
Safety Approval UL
Plug Wire Entry 180°
Wire Gauge or Range - mm² 0.14-1.5mm2
Wire Strip Length 7mm
Screw Size M2
Material Flammability Rating UL94 V-0
RoHS StatusRoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
In-Stock:452 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$19.730634$19.730634
10$18.613806$186.13806
100$17.560194$1756.0194
500$16.566221$8283.1105
1000$15.628509$15628.509

1857977 Product Details

1857977 Overview


Packaging is in the form of Screw.There is a Free Hanging (In-Line) mounting type for the device.An Bulk case is utilized for packaging the product.As a product of the COMBICON IMC Series, it can be found in this category.Additionally, there are other features, such as PA, 94V-0.Free Hanging is used to mount the part.With this part, you get a lot of benefits that you won't find in other Plug, Male Pins products.

1857977 Features


COMBICON IMC series

1857977 Applications


There are a lot of Phoenix Contact 1857977 Terminal Blocks applications.

  • Medical technology
  • Military Technology
  • Refrigeration control
  • All Electrical Machinery
  • Anywhere power is distributed
  • Communication
  • Telecommunications
  • Data Technology
  • Embedded systems
  • Instrumentation
