Name: 1850932
Brand: Phoenix Contact
SKU: 1850932
Price: 24.08000 USD
Availability: InStock

new

1850932

Manufacturer part number:1850932

Manufacturer:Phoenix Contact

Description:Bulk 0.150 3.81mm Green 1 Levels Free Hanging (In-Line) Plug, Female Sockets COMBICON FRONT-MC Polyamide (PA), Nylon Tin

Case Package:SOT-23

Datasheet:1850932 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	4 Weeks
Mount	Cable, Free Hanging, Panel
Mounting Type	Free Hanging (In-Line)
Material	Polyamide
Housing Material	Polyamide (PA), Nylon
Weight	153.999996g
Packaging	Bulk
Series	COMBICON FRONT-MC
Published	2011
Feature	Mating Flange
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN Code	EAR99
Connector Type	Screw
Type	Plug, Female Sockets
Color	Green
Number of Rows	1
Gender	Female
Voltage - Rated	160V
Additional Feature	PA, 94V-0
HTS Code	8536.69.40.40
Pitch	0.150 3.81mm
Orientation	Straight
Depth	21.7mm
Insulation Height	0.484 12.30mm
Current Rating	8A
Termination Style	Screw - Pressure Clip
Approval Agency	CB, CSA, VDE, cULus
Number of Contacts	10
Voltage	300V
Max Supply Voltage	160V
Max Current Rating	8A
Number of Levels	1
Current	8A
Wire Gauge (Max)	30 AWG
Wire Gauge (Min)	16 AWG
Contact Mating Finish	Tin
Number of Decks	1
Wire Gauge or Range - AWG	16-30 AWG
Voltage - IEC	320V
Torque - Screw	0.22-0.25 Nm (1.9-2.2 Lb-In)
Number of Ways	10
Safety Approval	UL
Plug Wire Entry	180°
Wire Gauge or Range - mm²	0.14-1.5mm2
Wire Strip Length	9mm
Screw Size	M2
Length	48.49mm
Width	21.7mm
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0

1850932 Product Details

1850932 Overview

Currently, it is packaged in Screw.The mounting type of the device is Free Hanging (In-Line).A Bulk case is used to package the product.A product of the COMBICON FRONT-MC Series, it belongs to the range of products of that series.Furthermore, there are other features available, such as PA, 94V-0, to name a few.A number of features make the Mating Flange feature more powerful.Cable, Free Hanging, Panel represents the mounting point for the part.This chip should not be supplied with voltages greater than zero.As with other Plug, Female Sockets products, this part also offers a wide range of benefits.
