Name: 1833124
Brand: Phoenix Contact
SKU: 1833124
Price: 30.16000 USD
Availability: InStock

new

1833124

Manufacturer part number:1833124

Manufacturer:Phoenix Contact

Description:1833124 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Phoenix Contact stock available on our website

Case Package:SOT-23

Datasheet:1833124 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	4 Weeks
Contact Plating	Tin
Mount	Cable, Panel
Mounting Type	Board Mount
Material	Polyamide
Housing Material	Polyamide (PA), Nylon
Weight	203.999993g
Packaging	Bulk
Published	2011
Series	COMBICON MCVU
Feature	Mating and Mounting Flange
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Screw
ECCN Code	EAR99
Connector Type	Plug, Screw
Type	Receptacle, Male Pins
Color	Green
Number of Rows	1
Gender	Female
Voltage - Rated	160V
Additional Feature	PA, 94V-0
HTS Code	8536.69.40.40
Pitch	0.150 3.81mm
Orientation	Straight
Depth	12.5mm
Insulation Height	0.492 12.50mm
Reach Compliance Code	unknown
Current Rating	8A
Termination Style	Screw - Rising Cage Clamp
Approval Agency	CB, CSA, VDE, cULus
Number of Contacts	12
Voltage	300V
Max Supply Voltage	160V
Max Current Rating	8A
Number of Levels	1
Current	8A
Wire Gauge (Max)	30 AWG
Wire Gauge (Min)	14 AWG
Number of Decks	1
Wire Gauge or Range - AWG	14-30 AWG
Voltage - IEC	320V
Torque - Screw	0.22-0.25 Nm (1.9-2.2 Lb-In)
Number of Ways	12
Safety Approval	UL
Wire Gauge or Range - mm²	0.14-1.5mm2
Wire Strip Length	7mm
Screw Size	M2
Height	20.3mm
Length	56.11mm
Width	12.5mm
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

1833124 Product Details

1833124 Overview

Plug, Screw packaging is included.Its mounting type is Board Mount.To package the product, we use a Bulk case.Among the products in the COMBICON MCVU Series, it is one of the most popular.Other features include PA, 94V-0, to name just a few.This feature makes it more powerful in a number of ways due to its Mating and Mounting Flange feature.Cable, Panel mounts the part.There should be no voltage over 160V on the supply line of this chip.With this part, you get a lot of benefits that you won't find in other Receptacle, Male Pins products.
