Home

1770898

  • 1770898 - 0.098 2.50mm Black Tape & Reel (TR) Liquid Crystal Polymer (LCP) Through Hole Horizontal with Board Screwless - Spring Cage, Tension Clamp 1 Levels 20-26 AWG COMBICON PTSM
  • 1770898 - 0.098 2.50mm Black Tape & Reel (TR) Liquid Crystal Polymer (LCP) Through Hole Horizontal with Board Screwless - Spring Cage, Tension Clamp 1 Levels 20-26 AWG COMBICON PTSM

1770898

1770898

Phoenix Contact

0.098 2.50mm Black Tape & Reel (TR) Liquid Crystal Polymer (LCP) Through Hole Horizontal with Board Screwless - Spring Cage, Tension Clamp 1 Levels 20-26 AWG COMBICON PTSM

SOT-23

1770898 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 4 Weeks
Contact PlatingTin
Mount Through Hole
Mounting Type Through Hole
Housing Material Liquid Crystal Polymer (LCP)
PackagingTape & Reel (TR)
Series COMBICON PTSM
Published 2010
Pbfree Code yes
Part StatusActive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screwless
ECCN Code EAR99
Number of Positions 3
Color Black
Voltage - Rated 200V
Pitch 0.098 2.50mm
Orientation Horizontal
Reach Compliance Code unknown
Current Rating6A
Wire Gauge20-26 AWG
Voltage 150V
Number of Levels 1
Current 5A
Wire Gauge (Max) 26 AWG
Wire Gauge (Min) 24 AWG
Terminal and Terminal Block Type STRIP TERMINAL BLOCK
Mating Orientation Horizontal with Board
Wire TerminationScrewless - Spring Cage, Tension Clamp
Height 8mm
Length 10mm
Width 10mm
RoHS StatusRoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
In-Stock:12766 items

Pricing & Ordering

QuantityUnit PriceExt. Price
1$0.484997$0.484997
10$0.457544$4.57544
100$0.431645$43.1645
500$0.407213$203.6065
1000$0.384163$384.163

1770898 Product Details

1770898 Overview


Through Hole is the mounting type of the device.We pack the product in a Tape & Reel (TR) case.This is from the COMBICON PTSM Series.This part is mounted by Through Hole.

1770898 Features


COMBICON PTSM series


1770898 Applications


There are a lot of Phoenix Contact
1770898 Terminal Blocks applications.


  • Communication
  • Medical technology
  • Military Technology
  • Measuring & Control Technology
  • Instrumentation
  • Automotive Electronics
  • Telecommunications
  • Data Technology
  • Blowers
  • Control panels
