Name: 1757022
Brand: Phoenix Contact
SKU: 1757022
Price: 3.30000 USD
Availability: InStock

new-10%

1757022

Manufacturer part number:1757022

Manufacturer:Phoenix Contact

Description:1757022 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Phoenix Contact stock available on our website

Case Package:SOT-23

Datasheet:1757022 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	5 Weeks
Contact Plating	Tin
Mount	Cable, Free Hanging
Mounting Type	Free Hanging (In-Line)
Insulation Material	Nylon
Housing Material	Polyamide (PA), Nylon
Weight	127.999996g
Packaging	Bulk
Published	1999
Series	COMBICON MSTB
Feature	Retention Latches (Non-Wire Side)
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Screw
ECCN Code	EAR99
Connector Type	Screw, Socket
Type	Plug, Female Sockets
Color	Green
Number of Rows	1
Gender	Male
Voltage - Rated	250V
Additional Feature	STANDARD: UL 94V-0, PA, SAFETY APPROVAL :VDE
Pitch	0.200 5.08mm
Orientation	Right Angle
Depth	18.2mm
Insulation Height	0.591 15.00mm
Current Rating	12A
Termination Style	Screw - Rising Cage Clamp
Voltage - Rated AC	250V
Approval Agency	UL, VDE
Lead Pitch	5.08mm
Number of Contacts	3
Voltage	300V
Max Supply Voltage	250V
Max Current Rating	12A
Number of Levels	1
Current	15A
Wire Gauge (Max)	30 AWG
Wire Gauge (Min)	12 AWG
Number of Decks	1
Wire Gauge or Range - AWG	12-30 AWG
Voltage - IEC	630V
Torque - Screw	0.5-0.6 Nm (4.4-5.3 Lb-In)
Number of Ways	3
Safety Approval	CB; CCA; CSA; CUL; EAC; UL
Plug Wire Entry	180°
Wire Gauge or Range - mm²	0.2-2.5mm2
Wire Strip Length	7mm
Screw Size	M3
Wire Cross Section	2.5 mm2
Height	15.24mm
Length	15.24mm
Width	18.3mm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

1757022 Product Details

1757022 Overview

The product is packaged in Screw, Socket.This device is mounted in the Free Hanging (In-Line) position.An orange Bulk case is used to package the product.Product number COMBICON MSTB belongs to the COMBICON MSTB Series.To name a few, there is also STANDARD: UL 94V-0, PA, SAFETY APPROVAL :VDE.Several benefits come from the Retention Latches (Non-Wire Side) feature.In this case, Cable, Free Hanging mounts the part.A supply voltage of 250V should not be exceeded by this chip.This part shares lots of benefits with other Plug, Female Sockets products.
