ECQ-E2185JFW

  • ECQ-E2185JFW - ECQ-E(F) 1.8μF Film Capacitor ±5% Radial PC Pins 250V-DC Polyester, Metallized Through Hole
  • ECQ-E2185JFW - ECQ-E(F) 1.8μF Film Capacitor ±5% Radial PC Pins 250V-DC Polyester, Metallized Through Hole

ECQ-E2185JFW

ECQ-E2185JFW

Panasonic Electronic Components

ECQ-E(F) 1.8μF Film Capacitor ±5% Radial PC Pins 250V-DC Polyester, Metallized Through Hole

SOT-23

ECQ-E2185JFW Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 15 Weeks
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial
Dielectric MaterialPolyester, Metallized
Operating Temperature-40°C~105°C
PackagingBulk
Published 2005
Series ECQ-E(F)
Size / Dimension 1.024Lx0.295W 26.00mmx7.50mm
Tolerance ±5%
Part StatusActive
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pins
Max Operating Temperature105°C
Min Operating Temperature -40°C
Applications General Purpose
Capacitance 1.8μF
Voltage - Rated DC 250V
Lead Pitch 15mm
Dielectric PET
Lead Spacing0.591 15.00mm
Height Seated (Max) 0.807 20.50mm
Length 26.0096mm
Width 7.493mm
RoHS StatusROHS3 Compliant
In-Stock:19124 items

Pricing & Ordering

QuantityUnit PriceExt. Price

ECQ-E2185JFW Product Details

ECQ-E2185JFW Overview


Lead spacing is 0.591 15.00mm for this electrical device.-40°C~105°C is the maximum temperature at which the device can operate.

ECQ-E2185JFW Features



ECQ-E2185JFW Applications


There are a lot of Panasonic Electronic Components ECQ-E2185JFW applications of film capacitors.

  • Switch-mode power supplies
  • Blocking
  • Filtering
  • Test and measuring equipment
  • Global positioning systems
  • Coupling, decoupling
  • VCO's
  • Satellite TV
  • TV and monitor sets
  • RF Modules
