PN2369A

Name: PN2369A
Brand: ON Semiconductor
SKU: PN2369A
Availability: InStock

new-10%

Manufacturer part number:PN2369A

Manufacturer:ON Semiconductor

Description:PN2369A datasheet pdf and Transistors - Bipolar (BJT) - Single product details from ON Semiconductor stock available on our website

Case Package:SOT-23

Datasheet:PN2369A Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mounting Type	Through Hole
Package / Case	TO-226-3, TO-92-3 (TO-226AA)
Surface Mount	NO
Transistor Element Material	SILICON
Operating Temperature	-55°C~150°C TJ
Packaging	Bulk
Published	2011
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	3
Subcategory	Other Transistors
Terminal Position	BOTTOM
Terminal Form	WIRE
Reach Compliance Code	unknown
Base Part Number	PN2369A
JESD-30 Code	O-PBCY-W3
Qualification Status	Not Qualified
Number of Elements	1
Configuration	SINGLE
Power - Max	350mW
Polarity/Channel Type	NPN
Transistor Type	NPN
DC Current Gain (hFE) (Min) @ Ic, Vce	40 @ 10mA 1V
Current - Collector Cutoff (Max)	400nA ICBO
Vce Saturation (Max) @ Ib, Ic	500mV @ 10mA, 100mA
Voltage - Collector Emitter Breakdown (Max)	15V
Current - Collector (Ic) (Max)	200mA
Transition Frequency	500MHz
Power Dissipation-Max (Abs)	0.625W
Collector-Base Capacitance-Max	4pF
