Name: NCV8843PWG
Brand: ON Semiconductor
SKU: NCV8843PWG
Availability: InStock

Technical Specifications

Parameter Name	Value
Type	Parameter
Lifecycle Status	OBSOLETE (Last Updated: 2 weeks ago)
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	16-SOIC (0.295, 7.50mm Width) Exposed Pad
Number of Pins	16
Operating Temperature	-40°C~150°C TJ
Packaging	Tube
Published	2010
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	16
ECCN Code	EAR99
Terminal Finish	Tin (Sn)
Additional Feature	ALSO OPERATES IN CURRENT MODE
Subcategory	Switching Regulator or Controllers
Terminal Position	DUAL
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	NCV8843
Function	Step-Down
Number of Outputs	1
Voltage - Input (Max)	40V
Output Type	Adjustable
Max Output Current	1.5A
Operating Supply Voltage	40V
Voltage - Input (Min)	4V
Input Voltage-Nom	5V
Analog IC - Other Type	SWITCHING REGULATOR
Output Configuration	Positive
Voltage - Output (Min/Fixed)	1.27V
Topology	Buck
Control Mode	CURRENT/VOLTAGE-MODE
Frequency - Switching	340kHz
Control Technique	PULSE WIDTH MODULATION
Synchronous Rectifier	No
Voltage - Output (Max)	38V
Height Seated (Max)	2.65mm
Width	7.5mm
RoHS Status	RoHS Compliant
Lead Free	Lead Free

NCV8843PWG Product Details

NCV8843PWG Overview

It uses the Tube package in order to optimize the performance of this voltage regulator. During the development of this harley voltage regulator, 16 terminations were made. A SWITCHING REGULATOR type of analog IC is equipped with this regulator voltage, which is the type of analog IC that is used in it. The harley voltage regulator is available as a 16-SOIC (0.295, 7.50mm Width) Exposed Pad package to save space. The voltage regulator is configured with 1 outputs. As you can see, this DC DC switching regulator generates Adjustable output on its output pins. A Surface Mount mounting is required for this switching regulator. Voltage regulators should be operated at -40°C~150°C TJ temperature while operating. DC-DC switching regulators reach 340kHz switching frequencies. Despite its low input voltage, this voltage regulator can operate. In this adjusting voltage regulator, the output voltage (Min/Fixed) equates to 1.27V. There is a voltage regulator maximum input voltage of 40V. This voltage regulator's peak reflow temperature is so high as to make it virtually indestructible. For operation, voltage regulator provides a nominal input voltage of 5V. The regulator voltage that you are looking at belongs to the subcategory Switching Regulator or Controllers. There is a DC/DC regulator in this family that belongs to the NCV8843 family. To operate the voltage regulator 12v, 16 pins are required. Accordingly, dc to dc voltage regulator's maximum output current is 1.5A A. By using 38V as the maximum output voltage, adjusting voltage regulator is easy to operate. Switching regulators such as this operate from voltages of 40V. Adding the ALSO OPERATES IN CURRENT MODE feature improves this switching regulator's efficiency and stability.
