NC7SZ38L6X Overview
The part comes in 6-UFDFN packaging, which makes it convenient to ship overseas. To ensure high reliability, a new packaging method Tape & Reel (TR) is used. A NAND Gate logic principle is used to make it work. It is necessary to ensure the full functionality of the part by providing a voltage of 1.65V~5.5V. Around -40°C~85°C is the extended operating temperature. There is a hole in Surface Mount for mounting the part. In both high and low states, output current is - 32mA. This item is from the 7SZ series. In total, 6 terminations have occurred. This part is equipped with 1 functions that will greatly enhance the user's experience. It is part of the LVC/LCX/Z family of chips. 7SZ38 can help you find device variants. Inputs for this part are 2. Circuits number 1 make up this device. It has a capacitance of 50pF when loaded. Upon reaching 5.5V, the highest supply voltage (Vsup) is reached. Contains the industry TAPE AND REEL method. Power supplies required for this part are specified in the datasheet as 3.3V. Standing by mode draws 2μA watts of current. The feature count is 0.
NC7SZ38L6X Features
NAND Gate Logic Type
Operating Temperature: -40°C~85°C
LVC/LCX/Z Family
