NC7SZ05P5 Overview
The part comes in 5-TSSOP, SC-70-5, SOT-353 packaging, which makes it convenient to ship overseas. To ensure high reliability, a new packaging method Tape & Reel (TR) is used. A Inverter logic principle is used to make it work. It is necessary to ensure the full functionality of the part by providing a voltage of 1.65V~5.5V. Around -40°C~85°C is the extended operating temperature. There is a hole in Surface Mount for mounting the part. In both high and low states, output current is - 32mA. This item is from the 7SZ series. In total, 5 terminations have occurred. This part is equipped with 1 functions that will greatly enhance the user's experience. It is part of the LVC/LCX/Z family of chips. 7SZ05 can help you find device variants. Many applications require the use of this logic device with its Surface Mount mounting. The datasheets for the 5 pins explain the functions. Parts in quiescent state carry 2μA current. Contains the industry TAPE AND REEL method. Power supplies required for this part are specified in the datasheet as 3.3V. During operation, there are 1 elements. The feature count is 0.
NC7SZ05P5 Features
Inverter Logic Type
Operating Temperature: -40°C~85°C
LVC/LCX/Z Family
Quiescent Current: 2μA
NC7SZ05P5 Applications
There are a lot of ON Semiconductor
NC7SZ05P5 Gates and Inverters applications.
- Computer
- Television
- Washing machine
- Range hood
- Refrigerator
- VCR
- Massager
- Fan
- Illumination
- Cell phone
