NB7V72MMNG Overview
Due to the lack of space on the board, digital switch is provided in the QFN.In this case, it is packaged as Tube.Its basic configuration includes terminations in the 16 range.The voltage supplied for multiplexer's system is 1.8V.multiplexer's systemThis turn signal switch has a total of 16 component pins.The supply type of this multiplexer ic is Single.The board has 16 pins configured.It is mounted in the way of Surface Mount.Multiplexer or Switches is a category for the digital switch ics.Supply voltages of 2.5V can provide reliable performance of the multiplexers.A total of 2 transmission channels are available in the turn signal switch's circuit.A maximum temperature of 85°C is acceptable for this signal switch.Maintaining a minimum operating temperature of the multiplexer of -40°C is recommended.The device is specified to operate at the maximum supply voltage of 2.625V in accordance with its applicable specification.According to its specifications, the digital swith requires a minimum supply voltage of 1.71V.The analog IC used by the digital switch is VIDEO MULTIPLEXER.
NB7V72MMNG Features
Supplied in the QFN package
Adopting a supply type of Single
Operating with the supply voltage of 2.5V
VIDEO MULTIPLEXER as the analog IC
NB7V72MMNG Applications
There are a lot of ON Semiconductor NB7V72MMNG Signal Switches / Multiplexers / Decoders applications.
- Analog to digital conversion
- Enabling different functions units in microprocessor instruction decoding
- Make full adder
- Injectors
- Microprocessor input/output systems
- Small scale TV wall
- Electronic circuits
- Automation system
- Relay
- Logic circuits
