Name: FDB039N06
Brand: ON Semiconductor
SKU: FDB039N06
Availability: InStock

new-10%

FDB039N06

Manufacturer part number:FDB039N06

Manufacturer:ON Semiconductor

Description:MOSFET N-CH 60V 120A D2PAK

Case Package:SOT-23

Datasheet:FDB039N06 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	36 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Weight	1.31247g
Operating Temperature	-55°C~175°C TJ
Packaging	Cut Tape (CT)
Series	PowerTrench®
Pbfree Code	yes
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Technology	MOSFET (Metal Oxide)
Number of Elements	1
Power Dissipation-Max	231W Tc
Element Configuration	Single
Power Dissipation	231W
Turn On Delay Time	30 ns
FET Type	N-Channel
Rds On (Max) @ Id, Vgs	3.9m Ω @ 75A, 10V
Vgs(th) (Max) @ Id	4.5V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds	8235pF @ 25V
Current - Continuous Drain (Id) @ 25°C	120A Tc
Gate Charge (Qg) (Max) @ Vgs	133nC @ 10V
Rise Time	40ns
Drive Voltage (Max Rds On,Min Rds On)	10V
Vgs (Max)	±20V
Fall Time (Typ)	24 ns
Turn-Off Delay Time	55 ns
Continuous Drain Current (ID)	174A
Gate to Source Voltage (Vgs)	20V
Drain to Source Breakdown Voltage	60V
Radiation Hardening	No
RoHS Status	RoHS Compliant
