Name: SPC5742PK1MLQ8
Brand: NXP USA Inc.
SKU: SPC5742PK1MLQ8
Availability: InStock

new-10%

SPC5742PK1MLQ8

Manufacturer part number:SPC5742PK1MLQ8

Manufacturer:NXP USA Inc.

Description:1.5MB 1.5M x 8 FLASH e200z4 32-Bit Dual-Core Microcontroller MPC57xx Series 144-LQFP

Case Package:SOT-23

Datasheet:SPC5742PK1MLQ8 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mounting Type	Surface Mount
Package / Case	144-LQFP
Surface Mount	YES
Operating Temperature	-40°C~125°C TA
Packaging	Tray
Series	MPC57xx
Published	2010
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	144
HTS Code	8542.31.00.01
Terminal Position	QUAD
Terminal Form	GULL WING
Terminal Pitch	0.5mm
JESD-30 Code	S-PQFP-G144
Qualification Status	Not Qualified
Power Supplies	1.253.3V
Oscillator Type	Internal
Speed	180MHz
RAM Size	192K x 8
Voltage - Supply (Vcc/Vdd)	3.15V~5.5V
Core Processor	e200z4
Peripherals	DMA, LVD, POR, WDT
Program Memory Type	FLASH
Core Size	32-Bit Dual-Core
Program Memory Size	1.5MB 1.5M x 8
Connectivity	CANbus, Ethernet, FlexRay, LINbus, SPI, UART/USART
Bit Size	32
Data Converter	A/D 64x12b
ROM (words)	1572864
RAM (bytes)	196608
RoHS Status	ROHS3 Compliant

SPC5742PK1MLQ8 Product Details

SPC5742PK1MLQ8 Overview

A 144-LQFP package is included. This Microcontroller is mounted using the Surface Mount mounting type. Powered by the 32-Bit Dual-Core core, it offers a wide range of capabilities. The type of memory that the program uses is FLASH. The temperature range of this Microcontroller is within the range of -40°C~125°C TA. MPC57xx series components belong to this electrical component. Its program memory size is 1.5MB 1.5M x 8. There is a e200z4 Core Processor inside MCU that provides this device with its power. Microcontroller is known that the chip has 144 terminations in total. The part works on a 32-bit basis.
