Name: MK22FN1M0AVLH12
Brand: NXP USA Inc.
SKU: MK22FN1M0AVLH12
Price: 19.44000 USD
Availability: InStock

new

MK22FN1M0AVLH12

Manufacturer part number:MK22FN1M0AVLH12

Manufacturer:NXP USA Inc.

Description:1MB 1M x 8 FLASH ARM® Cortex®-M4 32-Bit Microcontroller Kinetis K20 Series 3.3V 64-LQFP

Case Package:SOT-23

Datasheet:MK22FN1M0AVLH12 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	13 Weeks
Mounting Type	Surface Mount
Package / Case	64-LQFP
Surface Mount	YES
Operating Temperature	-40°C~105°C TA
Packaging	Tray
Series	Kinetis K20
Published	2002
JESD-609 Code	e3
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	64
ECCN Code	3A991.A.2
Terminal Finish	Tin (Sn)
HTS Code	8542.31.00.01
Terminal Position	QUAD
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
Supply Voltage	3.3V
Terminal Pitch	0.5mm
Time@Peak Reflow Temperature-Max (s)	40
JESD-30 Code	S-PQFP-G64
Supply Voltage-Max (Vsup)	3.6V
Supply Voltage-Min (Vsup)	1.71V
Oscillator Type	Internal
Number of I/O	40
Speed	120MHz
RAM Size	128K x 8
Voltage - Supply (Vcc/Vdd)	1.71V~3.6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	ARM® Cortex®-M4
Peripherals	DMA, I2S, LVD, POR, PWM, WDT
Clock Frequency	50MHz
Program Memory Type	FLASH
Core Size	32-Bit
Program Memory Size	1MB 1M x 8
Connectivity	CANbus, EBI/EMI, I2C, IrDA, SPI, UART/USART, USB, USB OTG
Bit Size	32
Data Converter	A/D 22x16b; D/A 1x12b
Has ADC	YES
DMA Channels	YES
PWM Channels	YES
DAC Channels	YES
Length	10mm
Width	10mm
RoHS Status	ROHS3 Compliant

MK22FN1M0AVLH12 Product Details

MK22FN1M0AVLH12 Description

MK22FN1M0AVLH12 microcontroller features several devices featuring peripheral sets targeted for a large number of applications. MK22FN1M0AVLH12 datasheet is an excellent option for a variety of extensive hardware and software ecosystems. MK22FN1M0AVLH12 NXP USA Inc. is suitable for Smart Power Socket and Light Switch, Motorcycle Engine Control Unit, Input Device, Smart Watch, and Wireless Charging Pad.
